L956 发动机电气总成 Engine electric system P4400-2944000116

1 14400342 扎带 Strip clamp Y 6

2 4011000664 螺栓GB5783-M14*20EpZn-8.8 Screw Y 1

3 29440000391 支板 Bracket Y 1

4 4011000461 螺栓GB16674-M8*16EpZn-8.8 Bolt Y 5

5 4190001095 扎丝N90666101 Cable tie Y 3

6 26370002431 红电瓶线护套 Cable sleeve Y 3

7 4041002416 管夹LGB169-B15*12.5 Clamp Y 1

8 4011000137 螺栓GB16674-M12*20EpZn-8.8 Bolt Y 3

9 4190001839 扎丝LG13-ZS4*160 Cable tie Y 6

10 4011000488 螺栓GB16674-M10*16EpZn-8.8 Bolt Y 2

11 26370001172 支架 Bracket Y 1

12 29440000731 支架 Bracket Y 1

13 29440000111 接地线P50*500 Battery cable Y 1

14 29370027641 电瓶线P25*1000 Battery cable Y 1

15 4011000194 螺钉GB818-M6*12EpZn-4.8 Screw Y 4

16 4015000207 垫圈GB97.1-6EpZn-300HV Washer Y 4

17 4130001480 保险丝座ANM-C Fuse box Y 1

18 4130001464 保险丝ANM 125 Fuse Y 1

19 29440000181 电瓶线A15*120 Battery cable Y 1

20 4130000869 中间继电器024-1Z6GD2 Relay Y 2

21 4130001988 接触器JCC200/1C24·48A Relay Y 1

22 4014000023 螺钉GB818-M5*10EpZn-4.8 Screw Y 2

23 4015000110 垫圈GB97.1-5EpZn-300HV Washer Y 2

24 29370027661 电瓶线P15*2000 Battery cable Y 1

25 4130002655 多态开关3735075-BD01 Switch Y 1

26 4130002780 应急提速开关JK931-01YJTS Rocker switch Y 1

27 4130002745 电子油门踏板403269 Accelerator pedal Y 1

28 4011000458 螺栓GB16674-M8*20EpZn-8.8 Bolt Y 3

29 29440001574 ECU线束 Wiring harness Y 1
