L955FC 散热器总成LG955N-2A（320204） Radiator A0394-4110003110

1 4110002975201 下钢架KB0476 Radiator frame N 1

2 4110002975202 防护网HB0242 Fan guard Y 2

3 4110002975203 导风罩DB0485 Fan shroud Y 1

4 4110003151102 左钢架KB0489 Radiator frame N 1

5 4110003151103 上钢架KB0491 Radiator frame N 1

6 4110002975206 中冷器S9112715A Air cooler Y 1

7 4110002975207 水散S9112699B Radiator Y 1

8 4110002945006 水箱盖711001 Cover Y 1

9 4110002975208 液压油散热器S9112715C Oil cooler Y 1

10 4110003151104 右钢架KB0490 Radiator frame N 1

11 4110002945015 法兰面螺栓614212 Screw N 36

12 4110002975218 支撑杆B330513 Bracket N 1

13 4110002975215 六角头螺栓610202 Screw N 4

14 4110002943004 弹垫632300 Spring washer N 4

15 4110001688022 平垫630330 Plain washer N 8

16 4110002945016 六角螺母621200 Nut N 4

17 4110002945007 放水阀739001 Valve Y 1

18 4110002506023 放水管8000080800 Hose Y 1

19 4110002286007 卡箍990002 Clamp N 1

20 4110002975216 减震垫720043 Damper mat N 4

21 4110002975217 支撑杆A330514 Bracket N 1
