L956F 双联泵80/40(120104) Gear pump I1901-4120006909

1 4120005082201 前盖163A002T Cover N 1

2 4120006909001 D类泵体163D293T Pump body N 1

3 4120005082203 B类泵体163B371T Pump body N 1

4 4120006909002 一级主齿163F146T Drive shaft N 1

5 4120005082205 二级主齿163G003T Drive shaft N 1

6 4120006909003 一级从齿163G022T Shaft N 1

7 4120005082207 二级从齿163G018T Shaft N 1

8 4120005082208 接轴163H0001 Shaft N 1

9 4120005082209 侧板163J002T Side board N 4

10 4120005082210 孔用弹性挡圈565C-00016 Retaining ring N 1

11 4120005082211 外置轴承W58-48 Beaing N 1

12 4120005082212 油封W62-26-10 Sealing ring N 1

13 4120005082213 滑动轴承002B005T Plain bearing N 8

14 4120005082214 堵油螺钉S-0280 Screw N 2

15 4120005082215 圆柱销008A0006 Pin N 4

16 4120005082216 O型密封圈001E0006 O-ring N 2

17 4120005082217 E型密封圈006E003T Sealing ring N 4

18 4120005082218 E型挡圈007E002T Retaining ring N 4

19 4120006909004 双头螺柱002A0038 Stud N 4

20 4120005082220 螺母004A0004 Nut N 4

21 4120005082221 垫圈W033-2 Washer N 4
