L955FC 后车架电气总成 Electric equipment P4200-2942000513

1 4130001412 制动压力开关YK-ZD Pressure switch Y 1

2 4190001839 扎丝LG13-ZS4*160 Cable tie Y 45

3 29440000191 电瓶线P15*300 Battery cable Y 1

4 4011001297 螺栓GB16674.1-M8*16flZnyc-8.8-480 Screw Y 10

5 11211133 接插件固定夹 Clip Y 1

6 4190001838 扎丝RTGB-370HD-S Cable tie Y 5

7 4130001299 压力开关YK212B/D1 Pressure switch Y 1

8 4130000202 温度传感器WDG1371 Temperature sensor Y 1

9 14400342 扎带 Strip clamp Y 3

10 29420005112 后车架线束 Wiring harness Y 1

11 14400341 扎带 Strip clamp Y 2

12 14400340 扎带座 Strip clamp Y 2

13 4130002901 后尾灯PL0658 Tail lamp Y 1

14 4014000026 螺钉GB818-M6*16EpZn-4.8 Screw Y 4

15 4015000207 垫圈GB97.1-6EpZn-300HV Washer Y 4

16 4130001294 隔膜式压力开关310-LGK1 Pressure switch Y 1

17 4130003144 后尾灯PL0658B Tail lamp Y 1

18 4130002615 后尾灯2SE 002 578-70 Tail lamp Y 2

19 29420005241 尾灯过渡线束 Wiring harness Y 1

20 29420003481 尾灯过渡线束 Wiring harness Y 1

21 4130001130 灯泡24V 21W(P21W) 8GA 002 073-241 Bulb Y 4

22 4130001131 灯泡24V 10W(R10W) 8GA 002 071-251 Bulb Y 2
