L936 燃油箱总成 Fuel tank A0201-2902002083

1 4110000613 带锁加油滤清器QL8 Fuel filter Y 1

2 4011000102 螺栓GB5783-M8*16EpZn-8.8 Bolt Y 4

3 4110000807 圆形油标YB-M42*1.5 Level gauge Y 2

4 4011000106 螺栓GB5783-M8*25EpZn-8.8 Bolt Y 2

5 4015000072 垫圈GB97.1-8EpZn-300HV Washer Y 2

6 29020006591 护板 Protecting plate Y 1

7 4014000047 螺钉GB818-M5*8EpZn-4.8 Screw Y 5

8 29020006841 法兰盖 Cover plate Y 1

9 29020006851 垫片 Spacer Y 1

10 29020006571 盖板 Cover plate Y 1

11 4030000022 O形圈GB3452.1-200*7.00G O-ring Y 1

12 29020006561 透气钢管 Tube Y 1

13 29020018601 滤油器总成 Strainer Y 1

14 3010900068 垫圈 Washer Y 1

15 4011000085 螺栓GB5783-M10*35EpZn-8.8 Bolt Y 6

16 4015000162 垫圈GB97.1-10EpZn-300HV Washer Y 6

17 29020018571 燃油箱体 Fuel tank N 1
