L920 配重 Counter weight K2800-2928001415

1 29280014161 平衡铁 Counterweight Y 1
2 4043001983 橡胶板LGB332-A1806010 Rubber plate Y 4
3 29340006841 锁紧镙杆 Bolt Y 4
4 29340006931 锁紧角钢 Corner steel Y 2
5 4013000033 螺母GB6170-M8EpZn-8 Nut Y 4
6 4015000036 垫圈GB93-8-65Mn Spring washer Y 2
7 4015000197 垫圈GB96.1-10EpZn-300HV Washer Y 4
8 4043002565 橡胶板LGB332-A2006020 Rubber plate Y 4
9 4013000064 螺母GB889.2-M302EpZn-8 Lock nut Y 2 10 4011000120 螺栓GB5785-M302*215EpZn-8.8 Bolt Y 2
11 29280007541 牵引销 Towing pin Y 1
12 29340011901 走线胶套 Rubber sleeve Y 2
