L918 液压操纵总成 Hydraulic control system F1200-2912003431

1 29120034391 液压操纵主管路模块 Hydraulic control N 1
2 29120034321 液压操纵先导管路模块 Hydraulic control system N 1

液压操纵先导管路模块 Hydraulic control system F1200-2912003432

1 4120001954 滤油器PLF-C30*10 Hydraulic fluid filter Y 1

2 4011001248 螺栓GB5783-M10*25flZnyc-8.8-480 Screw Y 2

3 4015000433 垫圈GB97.1-10flZnyc-300HV-480 Washer Y 2

4 29120015081 接头 Nipple Y 2

5 4030000276 O形圈GB3452.1-32.5*2.65G O-ring Y 2

6 29190007921 直通接头体 Nipple Y 1

7 29120014931 垫圈 Washer Y 15

8 4190000141 接头EW12LOMDA3C Nipple Y 1

9 29120009921 直通接头 Nipple Y 3

10 4041000592 软管LGB125-004055 Hose assembly Y 1

11 4120006641 先导阀总成DXS-00-B1 Control lever Y 1

12 4011001302 螺栓GB16674.1-M10*16flZnyc-8.8-480 Screw Y 3

13 4041000580 软管LGB125-004040 Hose assembly Y 1

14 4190000176 过渡接头EW10LOMDA3C Nipple Y 1

15 4011001299 螺栓GB16674.1-M10*25flZnyc-8.8-480 Screw Y 2

16 29120027921 固定板 Anchor plate Y 1

17 4011001350 螺栓GB16674.1-M10*60flZnyc-8.8-480 Screw Y 2

18 4120005063 压力选择阀SF8-D Valve Y 1

19 29120015661 固定板 Anchor plate Y 1

20 4011001337 螺栓GB16674.1-M12*20flZnyc-8.8-480 Screw Y 4

21 4011001470 螺栓GB16674.1-M8*70flZnyc-8.8-480 Bolt Y 4

22 4013000373 螺母GB6170-M8flZnyc-8-480 Nut Y 4

23 4015000430 垫圈GB97.1-8flZnyc-300HV-480 Washer Y 4

24 29120018741 橡胶管夹 Clamp Y 2

25 29120018751 橡胶管夹 Clamp Y 2

26 29120015381 板 Plate Y 2

27 4011001297 螺栓GB16674.1-M8*16flZnyc-8.8-480 Screw Y 2

28 29120007671 管夹 Clamp Y 4

29 4041001023 组合接头LGB143-01608 Nipple Y 1

30 4030000240 O形圈GB3452.1-8.00*1.80G O-ring Y 2

31 29120015701 动臂大腔至选择阀胶管 Hose assembly Y 1

32 29120015401 接头 Nipple Y 8

33 4041001927 软管LGB125-003290 Hose assembly Y 1

34 4041002446 软管LGB125-003295 Hose assembly Y 1

35 4041001434 软管LGB125-003245 Hose Y 1

36 4041001451 软管LGB125-003250 Hose Y 1

37 29120015671 固定板 Anchor plate Y 1

38 4041000855 软管LGB165-004085 Hose Y 1

39 4041000508 螺塞LGB135-01824 Plug Y 2

40 4041000768 O形圈LGB168-11524 O-ring Y 2

41 4041000709 直接头LGB120-01616 Nipple Y 1

42 4041000780 O形圈LGB168-11324 O-ring Y 2

43 4041000831 直接头LGB120-01816 Nipple Y 1

44 4041000502 软管LGB125-005075 Hose assembly Y 1

45 4041000774 螺塞LGB135-01422 Plug Y 1

46 4011000344 螺栓JB999-M14*1.5*32EpZn-35 Bolt Y 1

47 29120029011 先导阀进油胶管 Hose assembly Y 1

48 29120024241 先导回油管 Hose Y 1

49 4011000366 螺栓JB999-M18*1.5*40EpZn-35 Bolt Y 1

50 29120015221 垫圈 Washer Y 2
