L918 液压操纵主管路模块 Hydraulic control system F1200-2912003569

1 29120018651 多路阀固定板 Anchor plate Y 1

2 4011000479 螺栓GB16674-M12*30EpZn-8.8 Bolt Y 4

3 4013000011 螺母GB6170-M12EpZn-8 Nut Y 4

4 4015000168 垫圈GB97.1-12EpZn-300HV Washer Y 4

5 4120008616 多路阀HC-D6/3-140bar Control valve Y 1

6 4011000302 螺栓GB16674-M8*75EpZn-8.8 Bolt Y 3

7 4041000772 螺塞LGB135-11019 Plug Y 1

8 29120013381 垫圈 Washer Y 3

9 29120012681 直通接头 Nipple Y 1

10 4030000090 O形圈GB3452.1-28.0*2.65G O-ring Y 1

11 29120010471 组合直角接头 Elbow nipple Y 1

12 4030000501 O形圈GB3452.1-15.0*1.80G O-ring Y 1

13 29120032051 压板 Plate Y 1

14 29120032041 橡胶管夹 Clamp Y 2

15 4011001467 螺栓GB5782-M10*80flZnyc-8.8-480 Bolt Y 2

16 4013000370 螺母GB6170-M10flZnyc-8-480 Nut Y 2

17 4015000433 垫圈GB97.1-10flZnyc-300HV-480 Washer Y 4

18 4041000599 软管LGB165-014140 Hose assembly Y 1

19 4041000600 软管LGB128-012125 Hose assembly Y 1

20 4011001300 螺栓GB16674.1-M10*30flZnyc-8.8-480 Screw Y 4

21 4041000137 分体法兰LGB117-306400 Flange half Y 1

22 4030000279 O形圈GB3452.1-25.0*3.55G O-ring Y 1

23 29120006591 回油胶管 Hose assembly Y 1

24 4041000796 直接头LGB120-02628 Nipple Y 1

25 4041000779 O形圈LGB168-12331 O-ring Y 1

26 4041000685 O形圈LGB168-12631 O-ring Y 1

27 29120006551 组合直角接头 Nipple Y 1

28 4041000510 软管LGB129-012045 Hose assembly Y 1

29 4041000774 螺塞LGB135-01422 Plug Y 2

30 4041000767 O形圈LGB168-11124 O-ring Y 2

31 4011001509 螺栓GB16674.1-M12*45flZnyc-8.8-480 Bolt Y 2

32 29120030191 过渡块 Block Y 1

33 4041000598 堵塞LGB142-01604 Plug Y 2

34 4030000240 O形圈GB3452.1-8.00*1.80G O-ring Y 2

35 4041001535 螺塞LGB135-12436 Plug Y 2

36 29120018641 垫圈 Washer Y 2

37 29130026841 接头块 Connector Y 1

38 4030000504 O形圈GB3452.1-25.8*1.80G O-ring Y 1

39 29120018891 直接头 Nipple Y 1

40 4030000153 O形圈GB3452.1-37.5*2.65G O-ring Y 1

41 4041001533 直接头LGB120-11413 Nipple Y 2

42 4041001047 组合接头LGB143-01406 Nipple Y 1

43 4030000530 O形圈GB3452.1-6.00*1.80G O-ring Y 1

44 4041001223 软管LGB125-003060 Hose assembly Y 1

45 4041000680 堵塞LGB142-03016 Plug Y 1

46 4030000241 O形圈GB3452.1-20.0*1.80G O-ring Y 1
