Description
4110000186414 SDLG FLYWHEEL SHELL COMPONENTS C92AL-9H5921
| 4030000049 | 油封HG4-692-SG80*100*12 | OIL SEAL HG4-692-SG80*100*12 |
| 4021000030 | 滚动轴承GB297-31313 | BEARING GB297-31313 |
| 29070001171 | 轴承套 | BEARING SEAT |
| 29070000181 | 垫片 | SPACER |
| 29070001151 | 轴套 | SHAFT SLEEVE |
| 29070000191 | 垫片 | SPACER |
| 29070001201 | 调整垫片 | ADJUSTING SHIM |
| 29070000201 | 垫片 | SPACER |
| 4021000032 | 滚动轴承GB297-31314 | BEARING GB297-31314 |
| 29070000211 | 垫片 | SPACER |
| 29070000461 | 固定销 | PIN |
| 4021000036 | 滚动轴承GB297-32216 | BEARING GB297-32216 |
| 29070000351 | 调整螺母 | ADJUSTING NUT |
| 4016000124 | 销GB119.2-10u8*30 | PIN GB119.2-10u8*30 |
| 29070001221 | 托架 | CARRIER |
| 29070000311 | 锁紧片 | LOCKING LEAF |
| 4013000052 | 螺母GB6173-M27*2-05 | NUT GB6173-M27*2-05 |
| 29070000301 | 止推螺栓 | BOLT |
| 29070000391 | 轴承座 | CAGE |
| 29070000401 | 锁紧片 | LOCKING LEAF |
| 4015000025 | 垫圈GB93-10-65Mn | WASHER GB93-10-65Mn |
| 4011000597 | 螺栓GB5786-M10*1*20EpZn-8.8 | BOLT GB5786-M10*1*20EpZn-8.8 |
| 29070001301 | 垫圈 | WASHER |
| 4011000126 | 螺栓GB5786-M16*1.5*40EpZn-8.8 | BOLT GB5786-M16*1.5*40EpZn-8.8 |
| 29070009521 | 螺栓 | BOLT |
| 29070001211 | 主动螺旋伞齿轮（左） | SPIRAL BEVEL GEAR PINION(LEFT) |
| 4021000027 | 滚动轴承GB283-NUP2307 | BEARING GB283-NUP2307 |
| 4015000020 | 挡圈GB894.1-35-65Mn | RETAINER RING GB894.1-35-65Mn |
| 29070000331 | 锥齿轮垫片 | WASHER THRUST |
| 29070000341 | 锥齿轮 | GEAR PINION |
| 29070009511 | 垫圈 | WASHER |
| 4013000198 | 螺母GB6176-M16*1.5-10 | NUT GB6176-M16*1.5-10 |
| 29070000431 | 差速器左壳 | LEFT CASE DIFFERENTIAL MECHANISM |
| 29070000381 | 半轴齿轮垫片 | HALF AXLE GEAR SPACER |
| 29070000371 | 半轴齿轮 | HALF AXLE GEAR |
| 29070000411 | 十字轴 | CROSS AXLE |
| 29070000451 | 从动螺旋伞齿轮（右） | LARGE SPRIAL BEVELGEAR (RIGHT) |
| 29070000361 | 差速器右壳 | RIGHT CASE DIFFERENTIAL MECHANISM |
| 29070009491 | 螺栓 | BOLT |
| 29070009501 | 螺栓 | BOLT |
| 4015000098 | 垫圈GB93-16-65Mn | WASHER GB93-16-65Mn |
| 29070001321 | 托架总成 | BRACKET ASSEMBLY |
| 2050900103 | 主动螺旋伞齿轮(左) | GEAR |
| 2050900079 | 差速器左右壳 | LEFT 、RIGHT CASE DIFFERENTIAL MECHANISM |
