WD10G220E23(DHD10G0618) A01170-4110003316 Alternator bracket group

1 4110000924101 六角头螺栓90003802655 Screw Y 2
2 4110001016009 平垫圈90014040009 Plain washer Y 2
3 4110000924129 六角法兰面承面带齿螺栓90011430036 Screw Y 1
4 4110001048016 发电机安装支架612600090779 Bracket Y 1
5 4110000924114 弹簧垫圈90003931142 Spring washer Y 2
6 4110000924115 1型六角螺母90012210004 Nut Y 2
7 4110000924124 六角法兰面承面带齿螺栓612600061713 Screw Y 1

WD10G220E23(DHD10G0618) A01169-4110003316 Alternator group

1 4110000591036 2型全金属六角锁紧螺母90003888453 Nut Y 1
2 4110000924126 小垫圈90003930282 Washer Y 2
3 4110001015029 拉紧块612600090663 Block Y 1
4 4110000924127 1型六角螺母90003871319 Nut Y 1
5 4110000556263 交流发电机612600090808 Alternator Y 1
6 4110000924128 波形弹性垫圈90003932016 Washer Y 1
7 4110000556122 六角头螺栓615P00090003 Screw Y 1
8 4110000924125 六角头螺栓90011260010 Screw Y 1
9 4110000924122 鞍型弹性垫圈90003932025 Spring washer Y 1
10 4110000556210 压紧块612600090292 Block Y 1
11 4110001015030 拉紧螺栓612600090681 Screw Y 1

WD10G220E23(DHD10G0618) A01168-4110003316 General-use wire and sensor group

1 4110000556133 密封垫圈612600080802 Sealing ring Y 1
2 4110001014003 螺座612600010058 Seat Y 1
3 4110001592123 方头锥形螺塞 90017010001 Plug Y 1
