L953 4110002975 散热器总成LG955N-2(331008) Radiator assembly

1 4110002975401 导风罩6723575-01 Fan shroud Y 1

2 4110002909002 密封条678331-225 Sealing strip N 4

3 4110002909003 框架组件6721513-01 Radiator frame N 1

4 4110002909004 密封条678331-319 Sealing strip N 2

5 4110002909005 密封条6721538-01 Sealing strip N 2

6 4110002975402 平垫圈690095-05 Plain washer N 8

7 4110002909007 六角法兰面螺栓690020-108 Screw N 10

8 4110002282011 六角法兰面螺栓690020-110 Screw N 30

9 4110002975403 密封条6712417-46 Sealing strip N 1

10 4110002909009 安装板组件6721519-01 Plate N 1

11 4110002909010 六角法兰面螺栓690020-105 Screw N 14

12 4110002975404 挡风板6724664-01 Wind deflector N 1

13 4110002909013 风冷封条机油冷却器211751-01 Oil cooler Y 1

14 4110002909014 安装板6721522-01 Plate N 2

15 4110002909016 散热器（铝）312332-01 Radiator Y 1

16 4110002909017 橡胶垫6717711-01 Rubber plate N 7

17 4110002909018 减震垫6714253-01 Damper mat N 7

18 4110002909019 密封条678331-293 Sealing strip N 2

19 4110002909020 空空封条中冷器250640-01 Air cooler Y 1

20 4110002909021 拉杆6721524-01 Bracket N 1

21 4110002975405 挡风板6724663-01 Wind deflector N 2

22 4110002745008 六角法兰面螺母M8690017-17 Nut N 4

23 4110002909024 拉杆6721523-01 Bracket N 1

24 4110002975406 防护圈6723576-01 Fan guard Y 2

25 4110002909026 橡胶板6721537-01 Rubber plate N 2

26 4110000751305 管夹670558-01 Hose clamp Y 1

27 4110002909015 橡胶管670217-19 Hose N 1
