G9165 4110002575 输出部件YD13-103 Output parts

1 4110000076341 输出轴 YD13 303 001 Output shaft Y 1

2 4110000076338 输出齿轮 YD13 303 003 Z=53 Gear Y 1

3 4021000097 轴承GB283-NJ213ECJ/C3 Roller bearing Y 1

4 4110000076309 调整垫片 1204 308 062 Shim Y 1

5 4110000076170 压板4620303247 Anchor plate Y 2

6 4011000777 螺栓GB5783-M10*30-8.8 Screw Y 4

7 4110000145062 螺栓锁片 1269 302 164 Lock plate N 2

8 4110000076366 轴用密封圈0750 111 116 WTB,90*120*13 Sealing ring Y 2

9 4021000023 滚动轴承GB276-6311 Ball bearing Y 1

10 4110000076213 孔用挡圈0630 502 048 120*4 Retaining ring Y 3

11 4110000076268 调整垫片0769120338 Shim Y 1

12 4110000076245 轴套 0730 062 296 L=20 Bushing Y 1

13 4110002575004 输出法兰(SAE 7C,1/2″) YD13 303 006 Flange Y 1
