G9165 4110002575 输入部件YD13-102 Input parts

1 4110000076347 涡轮轴 YD13 302 002 Turbine shaft Y 1

2 4110000367064 球轴承 6308 C3 40*90*23 0750 116 139 Bearing Y 1

3 4110001321053 调整垫片0769 120 427 Shim N 1

4 4110000076210 轴用挡圈0630 501 031 40*1.75 Retaining ring Y 1

5 4110000076342 输入齿轮YD13 302 004 Z=50 Gear Y 1

6 4110000367067 滚柱轴承J209E/C3 45*85*19 0750 118 Bearing Y 1

7 4110000076256 搭扣密封环0734317252 Sealing ring Y 1

8 4110000076335 配油法兰YD13 302 001 Flange Y 1

9 4110000076357 纸垫 YD13 302 005 Gasket N 1

10 4110000076025 泵轮轴承座4642 301 136 Seat Y 1

11 4110000367069 纸垫 4644 301 262 Gasket N 1

12 4011000724 螺栓GB5783-M8*25-8.8 Bolt Y 8

13 4110000076027 搭扣密封环0734 401 078 Sealing ring Y 1

14 4110000367070 滚针轴承HK75*83*16 0735 298 027 Needle bearing Y 1

15 4110000076367 轴用密封圈 0750 111 231 75*100*10 Sealing ring Y 1

16 4110000076317 辅助驱动轴 YD13 302 003 Drive shaft Y 1

17 4110000076030 搭扣密封环 0634 402 025 Sealing ring Y 1

18 4110001321070 纸垫 4644 301 265 Gasket N 1

19 4110000076032 齿轮泵O501004171 Gear pump Y 1

20 4110000367073 球轴承6206RS/J30*62*16 0750 116 104 Bearing Y 2

21 4022000018 键GB1096-6*22-35 Flat key Y 1

22 4110000076209 轴用挡圈0630 501 024 30*1.5 Retaining ring Y 1

23 4011000303 螺栓GB5782-M8*85EpZn-8.8 Bolt Y 4

24 4011000588 螺栓GB5782-M8*110EpZn-8.8 Screw Y 4
