G9165 4110002575 发动机连接部件YD13-130 Engine connection parts

1 4110002575007 连接外壳 SAE2 (A=142) YD13 330 004 Housing Y 1
2 4110002575008 螺栓 Bolt M10×35 DIN933 10.9 Screw N 11
3 4110002575009 弹性圆柱销 Pin 10×28 DIN1481 Pin N 2
4 4110002575010 弹性圆柱销 Pin 6×30 DIN1484 Pin N 2
5 4110000076319 盖 YD13 330 003 Cover plate Y 1
6 4110000076358 纸垫 YD13 330 006 Gasket N 1
7 4011000722 螺栓GB5783-M610-8.8 Screw Y 4 8 4110002575011 膜片 4644 330 193B2 Diaphragm Y 1 9 4011000759 螺栓GB5783-M1020EpZn-10.9 Screw Y 4
10 4110002575012 垫圈L=6.4 4644 301 851 Plain washer N 1
11 4110000076308 垫圈4166 330 123 Washer Y 1
12 4110000076379 O形圈 0634 313 260 25×3 ZFN744 O-ring N 1
13 4015000283 挡圈GB893.1-30-65Mn Retaining ring Y 1
