LG953 4120005942 动臂油缸(3713CH) Boom cylinder

1 4120000558502 活塞杆241000079 Piston rod Y 1

2 4120000558501 密封件包 Sealing ring kit Y 1

3 4120000558501 密封件包 Sealing ring kit Y 1

4 4120000558501 密封件包 Sealing ring kit Y 1

5 4120000558501 密封件包 Sealing ring kit Y 1

6 4120000558501 密封件包 Sealing ring kit Y 1

7 4120000558503 缸盖243000033 Cover Y 1

8 4120000558501 密封件包 Sealing ring kit Y 1

9 4120000558501 密封件包 Sealing ring kit Y 1

10 4120000558501 密封件包 Sealing ring kit Y 1

11 4120000558504 缸体242000113 Cylinder tube Y 1

12 4120000558501 密封件包 Sealing ring kit Y 1

13 4120005685005 钢丝挡圈-孔用24C001140 D100*2.5t Retaining ring Y 1

14 4120000558501 密封件包 Sealing ring kit Y 2

15 4120000558501 密封件包 Sealing ring kit Y 1

16 4120000558501 密封件包 Sealing ring kit Y 1

17 4120000558501 密封件包 Sealing ring kit Y 1

18 4014000171 螺钉GB70.1-M8*25-8.8 Screw Y 1

19 4090000168 钢球GB308-5-GCr6 Ball Y 1

20 4120000558505 活塞244000132 Piston Y 1

21 4120005942022 衬套24S290402 Bushing Y 1

22 4120000558501 密封件包 Sealing ring kit Y 2

23 4015000098 垫圈GB93-16-65Mn Spring washer Y 12

24 4014000315 螺钉GB70.1-M16*55-12.9 Screw Y 12

25 4120000558507 耳环座249000004 Seat N 1
