LG953 4120005032 转斗油缸(3713CH) Tilt cylinder

1 4120005032001 活塞杆241000550 Piston rod Y 1

2 4120003967102 钢丝挡圈249200042 Retaining ring N 1

3 4120005032002 密封件包 Sealing kit Y 1

4 4120005032002 密封件包 Sealing kit Y 1

5 4120005032002 密封件包 Sealing kit Y 1

6 4120005032002 密封件包 Sealing kit Y 1

7 4120005032002 密封件包 Sealing kit Y 1

8 4120005032002 密封件包 Sealing kit Y 1

9 4120005032002 密封件包 Sealing kit Y 1

10 4120003967105 缸盖243000133 Cylinder head Y 1

11 4120003967104 钢丝挡圈249200054 Retaining ring N 1

12 4120005032003 缸体242000317 Cylinder tube Y 1

13 4120005032002 密封件包 Sealing kit Y 1

14 4120005032002 密封件包 Sealing kit Y 2

15 4120005032002 密封件包 Sealing kit Y 1

16 4120005032004 钢球490000004 Ball Y 1

17 4014000171 螺钉GB70.1-M8*25-8.8 Screw Y 1

18 4120005032002 密封件包 Sealing kit Y 2

19 4120003097005 活塞244000112 Piston Y 1

20 4120005032002 密封件包 Sealing kit Y 4

21 4120003097006 衬套Ⅰ-245000004 Bushing Y 1

22 4015000098 垫圈GB93-16-65Mn Spring washer Y 16

23 4120002263407 螺钉GB70.1-M16*55 Screw Y 16

24 4030000065 油杯JB7940.1-M10*1 Lubricating nipple Y 1

25 4120003097007 衬套Ⅱ-245000005 Bushing Y 1
