LG953 4120000684 齿轮泵(370101) Gear pump

1 4120000903101 挡圈GB893.1-86-70 Retaining ring Y 1
2 4120000903102 旋转轴唇形密封圈GB9877.1-88 Sealing ring Y 2
3 4120000903103 前盖CBGj3-02 Cover N 1
4 4120000903104 挡圈GB893.1-86-65 Retaining ring Y 1
5 4120000903111 矩形密封圈CBGj3-T1 Sealing ring Y 1
6 4120000903001 滚针轴承644708 Needle bearing Y 4
7 4120000903105 轴套CBGj3-08 Bushing Y 4
8 4120000903106 耳形挡片CBGj3-05 Retaining ring Y 2
9 4120000903107 耳形密封CBGj3-03 Sealing washer Y 2
10 4120000903108 侧板CBGj3-07 Side board Y 2
11 4120000903109 主动齿轮轴CBGj3/1-01 Drive shaft N 1
12 4120000903110 从动齿轮轴CBGj3-10 Shaft N 1
13 4120000903112 泵体Ⅰ CBGj3/1-02 Pump body N 1
14 4120000401001 后盖CBGj3-09 Cover Y 1
15 4120002486013 标牌（临工专用）临工BP-1 Name plate N 1
16 4019000001 铆钉GB827-2*4-BL2 Rivet Y 2
17 4120000903116 垫圈GB93-87-20 Washer Y 4
18 4120000903115 螺钉CBGj3-13-20 Screw Y 4
19 4120000903117 垫圈GB93-87-16 Washer Y 2
20 4120000903118 螺钉GB70-85-16 Screw Y 2
21 4120000401002 密封件包 Sealing ring kit Y 1
