LG953 2912001702 液压操纵系统 Hydraulic control system

1 4120002278 多路阀DFSY-32-18 Control valve Y 1

2 4041000774 螺塞LGB135-01422 Plug Y 2

3 4041000767 O形圈LGB168-11124 O-ring Y 2

4 29120016981 多路阀固定板 Anchor plate Y 1

5 4011000477 螺栓GB16674-M12*35EpZn-8.8 Bolt Y 4

6 4015000168 垫圈GB97.1-12EpZn-300HV Washer Y 10

7 4013000011 螺母GB6170-M12EpZn-8 Nut Y 8

8 29120009161 多路阀回油钢管 Pipe Y 1

9 4030000031 O形圈GB3452.1-42.5*3.55G O-ring Y 1

10 4011000230 螺栓GB16674-M10*65EpZn-8.8 Bolt Y 1

11 29120014981 多路阀进油胶管 Hose assembly Y 1

12 4030000029 O形圈GB3452.1-37.5*3.55G O-ring Y 3

13 4041000056 分体法兰LGB117-312550 Flange half Y 2

14 4011000475 螺栓GB16674-M10*30EpZn-8.8 Bolt Y 8

15 29120009121 支架 Bracket Y 1

16 4011000455 螺栓GB16674-M8*25EpZn-8.8 Bolt Y 2

17 29120009091 压板 Plate Y 1

18 29120009101 橡胶板 Rubber plate Y 2

19 4011000053 螺栓GB5782-M10*90EpZn-8.8 Bolt Y 2

20 4013000007 螺母GB6170-M10EpZn-8 Nut Y 4

21 4015000162 垫圈GB97.1-10EpZn-300HV Washer Y 2

22 29120015332 回油胶管 Hose assembly Y 1

23 4030000130 O形圈GB3452.1-47.5*3.55G O-ring Y 2

24 4041000011 分体法兰LGB117-314650 Flange half Y 2

25 4011000479 螺栓GB16674-M12*30EpZn-8.8 Bolt Y 8

26 4190000020 扎丝LG13-ZS4*250 Cable tie Y 4

27 29120017011 三通接头 Three-way nipple Y 1

28 4120002271 单向阀S8A120S Check valve Y 1

29 29120015221 垫圈 Washer Y 3

30 4120002280 先导阀总成DXS-00-S Control lever Y 1

31 29120015911 操纵箱盖PS Cover Y 1

32 29320008221 橡胶盖 Rubber cap Y 1

33 4011000488 螺栓GB16674-M10*16EpZn-8.8 Bolt Y 3

34 4014000058 螺钉GB70.1-M6*20EpZn-8.8 Screw Y 6

35 29120007651 接头 Nipple Y 2

36 29120014931 垫圈 Washer Y 12

37 4041001023 组合接头LGB143-01608 Nipple Y 3

38 4030000240 O形圈GB3452.1-8.00*1.80G O-ring Y 3

39 29120017131 先导阀进油软管 Hose assembly Y 1

40 4011000344 螺栓JB999-M14*1.5*32EpZn-35 Bolt Y 1

41 29120015401 接头 Nipple Y 8

42 29120017061 先导阀回油软管 Hose assembly Y 1

43 4011000366 螺栓JB999-M18*1.5*40EpZn-35 Bolt Y 1

44 29120015081 接头 Nipple Y 2

45 4030000276 O形圈GB3452.1-32.5*2.65G O-ring Y 2

46 4120001954 滤油器PLF-C30*10 Hydraulic fluid filter Y 1

47 4041001381 软管LGB125-004095 Hose assembly Y 1

48 4011000461 螺栓GB16674-M8*16EpZn-8.8 Bolt Y 3

49 29120007671 管夹 Clamp Y 3

50 29120017251 固定板 Anchor plate Y 1

51 4011000197 螺栓GB5783-M12*25EpZn-8.8 Bolt Y 2

52 29120017111 缓冲套 Rubber sleeve Y 1

53 4120002274 蓄能器GXQ-D-0.75L-100 Accumulator Y 1

54 29120017241 直接头 Nipple Y 1

55 29220000811 垫圈 Washer Y 1

56 29120017231 U形螺栓 U-bolt Y 1

57 4013000033 螺母GB6170-M8EpZn-8 Nut Y 2

58 4015000072 垫圈GB97.1-8EpZn-300HV Washer Y 2

59 29120016991 固定板 Anchor plate Y 1

60 4011000137 螺栓GB16674-M12*20EpZn-8.8 Bolt Y 6

61 4011000447 螺栓GB16674-M10*20EpZn-8.8 Bolt Y 2

62 29120017001 支架 Bracket Y 1

63 29120016741 管夹 Clamp Y 4

64 29120016351 固定板 Anchor plate Y 2

65 4011000493 螺栓GB16674-M8*90EpZn-8.8 Bolt Y 4

66 29120017741 固定板 Anchor plate Y 1

67 29120014961 多路阀进油块 Valve block Y 1

68 4011000136 螺栓GB16674-M10*85EpZn-8.8 Bolt Y 4

69 4041002180 软管LGB125-003320 Hose Y 1

70 4041002270 软管LGB124-004332 Hose assembly Y 1

71 29120017311 先导软管(a2-2a) Hose assembly N 1

72 4011000055 螺栓GB5782-M12*135EpZn-8.8 Bolt Y 2

73 4011000056 螺栓GB5782-M12*145EpZn-8.8 Bolt Y 1

74 4011000058 螺栓GB5782-M12*175EpZn-8.8 Bolt Y 1

75 29120017331 先导软管(b2-2b) Hose assembly N 1

76 29120017321 先导软管(b1-1b) Hose assembly N 1

77 4120001954001 滤芯（先导滤清器滤芯)PLFX-30X10 Filter insert Y 1
