LG953 2908000101 传动轴总成 Drive shaft assembly

1 4011000568 螺栓GB5786-M12*1.25*40EpZn-10.9 Bolt Y 24

2 4013000072 螺母GB889.2-M12*1.25EpZn-10 Lock nut Y 24

3 29080001021 后传动轴 Propeller shaft Y 1

4 29080008131 螺栓 Screw Y 12

5 4015000340 防松垫圈NL12 Washer Y 12

6 4110002086 前传动轴 Propeller shaft Y 1

7 2908000102006 突缘叉XGZL50.5.00-01-D Link yoke Y 2

8 2050900027001 十字轴总成W42118P Spider Y 2

9 4110001951002 卡簧504100C-01 Retaining ring Y 8

10 4110002086003 油杯M6 JB/T7940.1-1995 Grease cup N 2

11 4110002086001 突缘叉4501-01-001 Propeller shaft flange Y 1

12 2908000102002 卡簧W50L/K(R)-5820 Clip Y 8

13 4110001531001 十字轴万向节总成W50-45126-A Spider Y 2

14 2908000102001 突缘叉ZL50.5.8-03 Link yoke Y 1
