LG956L 4120002264 转斗油缸(3713CH) Tilt cylinder

1 4120002264002 缸筒总成24A136190 Cylinder tube Y 1

2 4120002264003 活塞杆24A111250 Piston rod Y 1

3 4120002264004 缸盖24A170750 Cover Y 1

4 4120002264401 密封件包 Sealing ring kit Y 1

5 4120002264401 密封件包 Sealing ring kit Y 1

6 4120002264401 密封件包 Sealing ring kit Y 1

7 4120002264401 密封件包 Sealing ring kit Y 1

8 4120002264401 密封件包 Sealing ring kit Y 1

9 4120003685002 钢丝挡圈24C001260 Retaining ring Y 1

10 4120002264401 密封件包 Sealing ring kit Y 1

11 4120002264401 密封件包 Sealing ring kit Y 1

12 4120002264401 密封件包 Sealing ring kit Y 1

13 4120002264005 活塞24A180290 Piston Y 1

14 4120002264401 密封件包 Sealing ring kit Y 1

15 4120002264401 密封件包 Sealing ring kit Y 2

16 4120002264401 密封件包 Sealing ring kit Y 1

17 4090000168 钢球GB308-5-GCr6 Ball Y 1

18 4120004489009 内六角圆柱头螺钉24T508251 M8x25L Hex. socket screw Y 1

19 4120002264401 密封件包 Sealing ring kit Y 2

20 4120004488007 弹性垫圈24T401602 D16 Spring washer Y 16

21 4120005801012 螺钉-内六角圆柱头24T516555 M16*55L Screw Y 16

22 4120002264006 轴套24C044010 Bushing Y 1

23 4120002264401 密封件包 Sealing ring kit Y 4

24 4120002264007 轴套24C044510 Bushing N 1

25 4120005801013 油杯24V2100A1 M10x1 Grease cup N 1
