LG956L 4120002263 动臂油缸（371368） Lifting cylinder assembly

1 4120001699003 丝座HSGF-160/90*812.5-1 Seat N 1

2 4120002263103 活塞杆HSGF-170/90*767-1 Piston rod Y 1

3 4120002263101 密封件包 Sealing ring kit Y 1

4 4120002263101 密封件包 Sealing ring kit Y 1

5 4120002263101 密封件包 Sealing ring kit Y 2

6 4120002263101 密封件包 Sealing ring kit Y 1

7 4120002263012 缸盖HSGF-170/90*767-4 Cover Y 1

8 4120002263101 密封件包 Sealing ring kit Y 1

9 4120002263101 密封件包 Sealing ring kit Y 1

10 4120002263101 密封件包 Sealing ring kit Y 1

11 4120002263105 缸体HSGF-170/90*767-2 Cylinder tube Y 1

12 4120002263101 密封件包 Sealing ring kit Y 2

13 4120002263101 密封件包 Sealing ring kit Y 1

14 4120002263101 密封件包 Sealing ring kit Y 2

15 4120002263006 螺钉M12*50 GB/T78-2000 Screw Y 1

16 4120002263106 活塞HSGF-170/90*767-3 Piston Y 1

17 4120002263010 锌铝合金套HSGF-170/90*767-7 Bushing Y 1

18 4120002263011 骨架防尘85*100*8 HSGF-170/90*767-8 Sealing ring Y 2

19 4011000791 螺栓GB5785-M18*1.5*70EpZn-10.9 Bolt Y 12

20 4110000014038 垫圈18 GB/T93-1987 Washer Y 12
