LG956L 2919001386 转向泵总成 Steering pump system

1 29190008891 出油块 Block Y 1

2 4011000476 螺栓GB16674-M10*70EpZn-8.8 Bolt Y 4

3 4030000029 O形圈GB3452.1-37.5*3.55G O-ring Y 2

4 4011000475 螺栓GB16674-M10*30EpZn-8.8 Bolt Y 12

5 4041000043 分体法兰LGB117-310490 Flange half Y 2

6 4030000026 O形圈GB3452.1-32.5*3.55G O-ring Y 2

7 4030000565 吸油胶管HG4-763-64*305 Hose assembly Y 1

8 4017000013 喉箍JB8870-d90 Clamp Y 4

9 4012000003 螺柱GB898-M12*35EpZn-8.8 Stud Y 4

10 4015000168 垫圈GB97.1-12EpZn-300HV Washer Y 4

11 4013000011 螺母GB6170-M12EpZn-8 Nut Y 4

12 4120004423 双联泵105/10 Gear pump Y 1

13 29110000043 泵用密封垫 Gasket Y 1

14 29190000041 转向泵吸油钢管 Pipe Y 1

15 4011000477 螺栓GB16674-M12*35EpZn-8.8 Bolt Y 4

16 4041000011 分体法兰LGB117-314650 Flange half Y 1

17 4030000235 O形圈GB3452.1-43.7*3.55G O-ring Y 1

18 29190008941 转向泵出油胶管 Hose assembly Y 1

19 29120009921 直通接头 Nipple Y 2

20 4030000057 垫圈JB1002-14-T2 Washer Y 2

21 4041001023 组合接头LGB143-01608 Nipple Y 2

22 4030000240 O形圈GB3452.1-8.00*1.80G O-ring Y 2

23 29200005051 优先阀进油钢管 Pipe Y 1

24 4041000027 分体法兰LGB117-312551 Flange half Y 1

25 4041000645 软管LGB165-004130 Hose assembly Y 1

26 4190001839 扎丝LG13-ZS4*160 Cable tie Y 2

27 4041002371 软管LGB126-004128 Hose assembly Y 1

28 4041000604 直接头LGB120-01614 Nipple Y 1

29 4041000775 O形圈LGB168-21124 O-ring Y 1
