G9190 4110003431 离合器4644.153.234(450201) Clutch

1 7200001627 端垫4642308185 Washer Y 2
2 7200001628 活塞4644353062 Cylinder piston Y 1
3 7200001628 活塞4644353062 Cylinder piston Y 1
4 7200001629 贴面密封圈0750112141 Sealing ring Y 2
5 7200001551 密封环0750112140 Sealing ring Y 2
6 7200001552 压力弹簧0732041183 Spring Y 2
7 7200001553 导向环4642308083 Guide ring Y 4
8 7200001554 V形杯AV550630531346 Lock ring Y 2
9 7200001555 导向环4642308084 Guide ring Y 2
10 7200001637 滚针轴承0750115182 Needle bearing Y 1
11 7200001557 挡圈0730513610 Retaining ring Y 1
12 7200001639 滚针轴承0635303204 Needle bearing Y 1
13 7200001559 挡圈0730513611 Retaining ring Y 1
14 4110000042025 挡圈A= 2.50 0730 513 180 Retaining ring Y 1
15 4110000042024 挡圈A= 2.45 0730 513 416 Retaining ring Y 1
16 4110000042022 挡圈A= 2.40 0730 513 417 Retaining ring Y 1
17 4110000042021 挡圈A= 2.35 0730 513 418 Retaining ring Y 1
18 4110000042019 挡圈A= 2.30 0730 513 419 Retaining ring Y 1
19 7200001641 挡圈0730513420 A=2.25 Retaining ring Y 1
20 4110000042017 挡圈A= 2.20 0730 513 421 Retaining ring Y 1
21 4110000042016 挡圈A= 2.15 0730 513 455 Retaining ring Y 1
22 4110000042014 挡圈A= 2.10 0730 513 456 Retaining ring Y 1
23 7200001648 摩擦片支承4644253045 Support Y 1
24 7200001649 外摩擦片0501332095 Friction disc Y 10
25 4110002230045 外摩擦片0501 312 280 Friction disc Y 1
26 7200001650 内摩擦片4642308330 Friction disc Y 8
27 7200001652 内摩擦片4642308331 Friction disc Y 1
28 7200001651 内摩擦片4642308332 Friction disc Y 1
29 7200001650 内摩擦片4642308330 Friction disc Y 1
30 7200001652 内摩擦片4642308331 Friction disc Y 1

31 7200001649 外摩擦片0501332095 Friction disc Y 9
32 7200001650 内摩擦片4642308330 Friction disc Y 4
33 7200001651 内摩擦片4642308332 Friction disc Y 2
34 7200001652 内摩擦片4642308331 Friction disc Y 1
35 7200001651 内摩擦片4642308332 Friction disc Y 1
36 7200001650 内摩擦片4642308330 Friction disc Y 1
37 7200001652 内摩擦片4642308331 Friction disc Y 1
