G9190 4110003431 离合器4644.152.546(450201) Clutch

1 7200001575 轴4644352062 Shaft Y 1
2 7200001533 O形圈(49*3)0634313536 O-ring Y 1
3 7200001534 活塞环0734401106 Piston ring Y 3
4 7200001674 螺柱0636610014 Stud Y 2
5 7200001675 六角螺母(M8)0637006018 Nut Y 2
6 7200001539 止推垫圈0730150759 Thrust washer Y 1
7 7200001540 止推垫圈4644303529 Thrust washer Y 1
8 4110002230042 齿轮4644 351 090 Gear Y 1
9 7200001626 止推垫圈0730150777 Thrust washer Y 1
10 4110002230043 轴承0750 115 028 Needle bearing Y 2
11 7200001549 止推垫圈4644351094 Thrust washer Y 1
12 7200001550 止推垫圈4642308555 Thrust washer Y 1
13 7200001561 止推垫圈0730150779 Thrust washer Y 1
14 4110002230044 齿轮4644 252 065 Gear Y 1
15 7200001606 球轴承0750115211 Ball bearing Y 1
16 7200001566 角环0501308830 Spacer Y 3
