G9190 2808000202 前桥 Front axle

1 28080002231 左转向总成 Steering knuckle Y 1

2 28080002541 右旋球头 Ball joint Y 2

3 4013000319 锁紧螺母GB6173-M30×1.5-10 Nut Y 2

4 4120004762 前轮倾斜油缸 100*50*169-473 Cylinder Y 1

5 28080002321 右转向总成 Steering knuckle Y 1

6 4120004763 前轮转向油缸右 63*45*340-577 Steering cylinder Y 1

7 4120004764 前轮转向油缸左63*45*340-577 Steering cylinder Y 1

8 28080002181 铰接轴 Steering knuckle Y 2

9 28080002381 铰接轴 Steering knuckle Y 2

10 28080002131 转向横拉杆 Tie rod Y 1

11 4011000510 螺栓GB5782-M16*50EpZn-8.8 Bolt Y 2

12 4040000002 垫圈LGB001-16 Washer Y 2

13 28080002421 支座 Spacer Y 2

14 4015000167 垫圈GB97.1-24EpZn-300HV Washer Y 4

15 4016000057 开口销GB91-4*45EpZn-Q235A Split pin Y 4

16 28080002551 螺母 Nut Y 2

17 28080002451 衬套 Bushing Y 2

18 4021000289 关节轴承GB9163-GEG40ES-2RS Spherical plain bearing Y 2

19 4015000199 挡圈GB893.1-68-65Mn Retaining ring Y 2

20 4015000132 挡圈GB894.1-40-65Mn Retaining ring Y 3

21 28080002141 复合轴承 Bearing Y 4

22 28080002261 锁止垫片 Thrust bearing Y 6

23 4030000065 油杯JB7940.1-M10*1 Lubricating nipple Y 6

24 4015000186 垫圈GB96.1-12EpZn-300HV Washer Y 2

25 28080002351 铰接轴 Steering knuckle Y 1

26 4011000091 螺栓GB5783-M12*40EpZn-8.8 Bolt Y 1

27 28080002441 支座 Spacer Y 1

28 4011000089 螺栓GB5783-M12*30EpZn-8.8 Bolt Y 2

29 28080002431 支座 Spacer Y 2

30 4021000290 向心关节轴承GE35ES-2RS Spherical plain bearing Y 2

31 4015000272 P挡圈GB893.1-55-65Mn Retaining ring Y 2
32 28080002461 隔板 Spacer plate Y 2
33 28080002151 复合轴承 Bearing Y 2
34 28080002031 前桥架 Axle frame Y 1
35 28080002221 连杆 Link rod Y 1
36 4016000329 销GB882-B3090EpZn-35 Pin Y 1

37 4016000040 开口销GB91-6.350EpZn-Q235A Split pin Y 1
38 28080002851 前桥标牌 Name plate N 1
39 4019000012 铆钉GB827-3*5-BL2 Rivet Y 4
