LG916 4120005371 多路阀(43214) Control valve

1 4013000205 螺母GB6170-M16EpZn-10 Nut Y 8

2 4015000098 垫圈GB93-16-65Mn Spring washer Y 8

3 4120006260001 进油阀体ZL20-01 Valve body N 1

4 4120006260002 安全阀(过载阀)ZL20-02-00 Safety valve Y 3

5 4120006260003 标牌ZL20-18 Name plate N 1

6 4019000001 铆钉GB827-2*4-BL2 Rivet Y 4

7 4120006260004 换向阀体(并联型)ZL20-03 Valve body N 2

8 4120006260005 换向阀体(串联型)ZL20-08 Valve body N 1

9 4014000128 螺钉GB70-M8*25EpZn-8.8 Screw Y 8

10 4015000036 垫圈GB93-8-65Mn Spring washer Y 8

11 4120006260006 手柄架ZL20-13 Bracket N 2

12 4120006260007 防尘圈ZL20-14 Sealing ring N 3

13 4120005371013 O型密封圈31*3.5 GB1235-76 O-ring Y 3

14 4120006260008 阀杆(O型)ZL20-04 Valve rod N 1

15 4120006260009 阀杆(Q型)ZL20-09 Valve rod N 1

16 4120006260010 端盖ZL20-05-01 Cover N 1

17 4120006260011 限位柱ZL20-05-03 Block N 1

18 4120006260012 弹簧座ZL20-05-02 Spring seat N 2

19 4120006260013 弹簧ZL20-05-04 Adjusting spring N 1

20 4120006260014 挡板ZL20-05-05 Baffle N 1

21 4120005371015 O型密封圈85*3.1 GB1235-76 O-ring Y 4

22 4120006260015 端盖ZL20-10-01 Cover N 1

23 4120006260016 定位套ZL20-10-02 Spacer sleeve N 1

24 4090000097 钢球GB308-6-GCr15 Ball N 2

25 4120006260017 弹簧ZL20-07-01 Adjusting spring N 1

26 4120006260018 限位柱ZL20-07-02 Block N 1

27 4120005371013 O型密封圈31*3.5 GB1235-76 O-ring Y 1

28 4120006260019 阀套ZL20-10-03 Valve sleeve N 1

29 4030000464 PO形圈GB1235-40*3.1 O-ring Y 1

30 4120006260020 单向阀盖ZL20-16 Cover N 3

31 4120005371019 O型密封圈24*2.4 GB1235-76 O-ring Y 3
32 4120006260021 弹簧ZL20-15 Adjusting spring N 3
33 4120006260022 φ19钢球ZL20-17 Ball N 3
34 4120006260023 回油阀体(过桥油路用)ZL20-11a(b) Valve body N 1
35 4120006260024 联接螺栓ZL20-12 Stud N 4
