LG916 4110002137 倒退高档离合器(370710) Backward high-end clutch

1 4110002137001 垫圈ZL15.5.1-12 Washer Y 1

2 4021000190 止动环GB305-80/86.6 Retaining ring Y 2

3 4021000170 P轴承GB276-6208N Ball bearing Y 2

4 4110002137002 挡圈ZL15.5.1-1 Retaining ring Y 1

5 4015000046 挡圈GB894.1-50-65Mn Retaining ring Y 2

6 4110002137019 齿轮 ZL15.5.1-2 Gear N 1

7 4110002137004 弹簧座圈ZL50D.21.1-6 Spring seat Y 2

8 4110002137005 离合器弹簧ZL15.5.1-5 Spring Y 2

9 4015000300 挡圈GB893.1-150-65Mn Retaining ring Y 2

10 4110002137006 离合器活塞压板ZL15.5.1-3 Plate Y 2

11 4110002137007 离合器被动片ZL15.5.1-4 Friction disc Y 8

12 4110002137024 离合器主动片ZL15.5.1.3 Friction disc Y 8

13 4030000035 O形圈GB3452.1-53.0*5.30G O-ring Y 2

14 4110002137009 活塞ZL15.5.1.1-1 Piston Y 2

15 4110002137026 密封环ZL15.5.1-8 Sealing ring Y 2

16 4110002137027 倒退高档离合器壳体ZL15.5.2.1 Housing Y 1

17 4110002137028 内六角螺塞ZG1/8 07043-00108 Plug Y 2

18 4110002137029 外封环ZL15.5-36 Sealing ring Y 3

19 4021000017 滚动轴承GB276-6209 Ball bearing Y 2

20 4015000016 挡圈GB893.1-85-65Mn Retaining ring Y 2

21 4110002137030 挡环 ZL15.5.2-1 Retaining ring Y 1

22 4021000021 滚动轴承GB276-6308 Ball bearing Y 2

23 4011000747 螺栓GB5783-M12*30EpZn-10.9 Screw Y 6

24 4110002137031 齿轮ZL15.5.2.2-1 Gear Y 1

25 4110002137032 齿轮 ZL15.5.2.2-2 Gear Y 1

26 4110002137033 隔套ZL15.5.2-2 Sleeve Y 1

27 4110002137034 止动垫ZL15.5.2.2-3 Retaining ring N 3
