LG916 2913001705 举升缸总成 Lift cylinder

1 4120005335 动臂油缸HSGL-80*50*582-912 Lifting cylinder Y 2

2 29130017181 举升缸小腔钢管 Pipe Y 2

3 4030000490 O形圈GB3452.1-10.0*1.80G O-ring Y 4

4 29130017061 举升联小腔钢管 Pipe Y 1

5 29130017101 举升联大腔钢管 Pipe Y 1

6 4041002067 软管LGB127-010064 Hose assembly Y 1

7 4041001815 软管LGB127-010066 Hose assembly Y 1

8 29130017141 举升缸大腔钢管 Pipe Y 2

9 4041001040 直接头LGB155-02726 Joint Y 2

10 4030000090 O形圈GB3452.1-28.0*2.65G O-ring Y 2

11 29130017221 压板 Plate Y 2

12 4011000164 螺栓GB16674-M10*35EpZn-8.8 Bolt Y 2

13 29130017211 管夹 Hose clamp Y 2

14 4011000102 螺栓GB5783-M8*16EpZn-8.8 Bolt Y 6

15 4015000072 垫圈GB97.1-8EpZn-300HV Washer Y 4

16 4015000256 垫圈GB96.1-8EpZn-300HV Washer Y 2

17 4041002068 软管LGB127-005101 Hose assembly Y 4
