G9220 4110002230 输入装置4644 102 134 Input equipment

4110000367063 涡轮轴 4644 302 188 Shaft Y 1
2 7200001471 张紧销钉(2.5×5)0631329267 Pin Y 1
3 7200001472 张紧销钉(1.5×5)0631329124 Pin Y 1
4 4110000367064 球轴承 6308 C3 409023 0750 116 139 Bearing Y 1
5 4110001742007 调整垫圈 4607 302 006-014,033,034 Shim Y 1
6 7200001475 卡环0630501031 Lock ring Y 1
7 7200001476 主动齿轮(Z=52)4644302206 Gear Y 1
8 4110000367067 滚柱轴承J209E/C3 458519 0750 118 Bearing Y 1
9 4110000076256 搭扣密封环0734317252 Sealing ring Y 1
10 7200001479 进油法兰4644302250 Flange Y 1
11 7200001480 密封垫4644302211 Gasket Y 1
12 7200001481 轴承盖4642301136 Cover plate Y 1
13 7200001482 密封垫4644301262 Gasket Y 1
14 7200001483 六角螺钉(M8x28)0636015092 Screw Y 8
15 4110000076027 搭扣密封环0734 401 078 Sealing ring Y 1
16 4110000367070 滚针轴承HK758316 0735 298 027 Needle bearing Y 1
17 4110000076367 轴用密封圈 0750 111 231 7510010 Sealing ring Y 1
18 7200001487 输出轴4644311239 Output shaft Y 1
19 7200001488 活塞环(30×2)0634402025 Piston ring Y 1
20 7200001489 密封垫4644301265 Gasket Y 1
21 4110000042013 齿轮泵0750 132 143 Gear pump Y 1
22 4110000367073 球轴承6206RS/J306216 0750 116 104 Bearing Y 1
23 7200001492 滑键(A6x4x28)0631501052 Key Y 1
24 4110000367073 球轴承6206RS/J306216 0750 116 104 Bearing Y 1
25 4110001742008 调整垫圈 0730 001 591-600 Shim Y 1
26 7200001495 六角螺钉(M8x85)0636010111 Screw Y 4
27 7200001496 六角螺钉(M8x115)0636010123 Screw Y 4
28 7200001497 卡环 30×1.50630501024 Lock ring Y 2
