LG920 4120001985 空气加力泵(46455) Pneumatic cylinder

1 4120001985006 塑料堵盖HP3.5-40-41 M12*1.2 Plastic plug Y 1

2 4120001985007 端盖 HP3.5-40-01 Cover Y 1

3 4120001985031 密封件包 Sealing ring kit Y 1

4 4120001985008 油缸 HP3.5-40-03 Cylinder Y 1

5 4014000055 螺钉GB70.1-M12*30EpZn-8.8 Screw Y 1

6 4120001985009 油缸活塞头 HP3.5-40-28A-01 Brake piston Y 1

7 4120001985010 阀杆 HP3.5-40-04 Valve rod Y 1

8 4120001985011 阀门 HP3.5-40-05 Valve Y 1

9 4120001985012 进油接头HP3.5-40-11 Nipple Y 1

10 4120001985013 进油阀衬套 HP3.5-40-08A Bushing Y 1

11 4120001985014 进油阀弹簧HP3.5-40-06 Spring Y 1

12 4120001985015 进油阀弹簧座HP3.5-40-07 Spring seat Y 1

13 4015000282 垫圈GB93-3-65Mn Washer Y 1

14 4014000581 P-螺钉GB818-M3*5EpZn-4.8 Screw Y 1

15 4120001985016 油杯滤网HP3.5-40-16B Strainer Y 1

16 4120001985017 油杯膜片HP3.5-40-14 Diaphragm Y 1

17 4120001985018 油杯盖HP3.5-40-15A M85*2 Cover Y 1

18 4120001985019 螺母M27*1.5 Nut Y 1

19 4120001985031 密封件包 Sealing ring kit Y 2

20 4120001985020 油杯体HP3.5-40-17FT Cup Y 1

21 4120001985021 连接圈HP3.5-40-18B Attaching frame Y 1

22 4120001985022 汽缸体HP3.5-40-21B Cylinder block Y 1

23 4015000485 P-垫圈GB7244-8 Washer Y 6

24 4011000632 螺栓GB5783-M8*16-8.8 Bolt Y 6

25 4120001985031 密封件包 Sealing ring kit Y 1

26 4016000377 P-销GB119.2-3*8 Pin Y 1

27 4013000428 P-螺母GB810-M45*1.5EpZn-8 Nut Y 1

28 4120001985023 汽缸回位弹簧HP3.5-40-27 Spring Y 1

29 4120001985031 密封件包 Sealing ring kit Y 1

30 4120001985024 汽缸活塞体HP3.5-40-23 Piston Y 1

31 4120001985029 推盘HP3.5-40-24A Disc Y 1
32 4014000136 螺钉GB70.1-M1240EpZn-8.8 Screw Y 1 33 4015000026 垫圈GB93-12-65Mn Spring washer Y 2 34 4120001985025 塑料堵盖HP3.5-40-28A-02 M221.5 Plastic plug Y 1
35 4120001985026 油缸活塞杆HP3.5-40-28A-02 Piston rod Y 1
36 4120001985031 密封件包 Sealing ring kit Y 1
37 4120001985031 密封件包 Sealing ring kit Y 1
38 4120001985031 密封件包 Sealing ring kit Y 1
39 4120001985031 密封件包 Sealing ring kit Y 1
40 4120001985030 导向环HP3.5-40-39 Guide ring Y 2
41 4120001985027 呼吸螺栓总成HP.FC-00 Bolt Y 1
42 4019000001 铆钉GB827-2*4-BL2 Rivet Y 2
43 4120001985028 标牌BP-SDLG-02 Name plate N 1
