LG920 4110000218 输入部分(370804) Input shaft

1 4110000218108 轴承盖BDX05-00001 Cover Y 2

2 4110000218038 垫片BDX05-00002 Rubber washer Y 2

3 4110000218039 垫片BDX05-00003 Rubber washer Y 1

4 4110000218109 轴承座BDX05-00004 Seat Y 1

5 4110000218101 输入法兰盘BDX05-01000 Flange Y 1

6 4110000218092 密封垫BDX05-00006 Gasket Y 1

7 4110000218045 调整垫BDX05-00008 Shim Y 1

8 4110000218102 输入轴BDX05-00009 Input shaft Y 1

9 4110000218015 齿轮BDX05-00010 Gear Y 1

10 4110000218021 传动箱壳体BDX05-00011 Housing Y 1

11 4110000218065 管接头BDX05-00012 Nipple Y 1

12 4110000218075 开口销04050-04030 Pin Y 1

13 4110000960004 螺栓01010-81230 Screw Y 4

14 4110000160054 垫圈01602-21236 Gasket Y 4

15 4110000218057 骨架油封 07012-00048 Sealing ring Y 1

16 4110000218004 O 形圈07000-02105 105*2.5 O-ring Y 1

17 4021000021 滚动轴承GB276-6308 Ball bearing Y 1

18 4021000169 P轴承GB276-6006 Ball bearing Y 1

19 4110000960010 螺栓Bolt M10X30 01010-81030 Screw Y 15

20 4015000381 垫圈GB7244-10-65Mn Washer N 21

21 4110000960005 螺栓01010-81025 Screw Y 6

22 4110000218005 O 形圈07000-03032 32*3.5 O-ring Y 1

23 4110000218022 大垫圈01643-32260 Washer Y 1

24 4110000218080 螺母BD05-00010 Nut Y 1
