LG920 2927001081 后车架附件 Rear frame system

1 29250007971 前转向销轴 Pin Y 2

2 4043000326 垫片LGB303-35*60*1 Shim Y 4

3 4043000327 垫片LGB303-35*60*2 Shim Y 4

4 4011000081 螺栓GB5783-M10*20EpZn-8.8 Bolt Y 2

5 4040000008 垫圈LGB001-10 Washer Y 2

6 4030000065 油杯JB7940.1-M10*1 Lubricating nipple Y 4

7 29270006582 副车架前油管 Lubricating pipe Y 1

8 29250000311 管夹 Clamp Y 2

9 4014000024 螺钉GB818-M6*10EpZn-4.8 Screw Y 4

10 4015000035 垫圈GB93-6-65Mn Spring washer Y 4

11 29270006601 副车架后油管 Lubricating pipe Y 1

12 4043000663 销轴LGB301-40*70R*120G-40Cr Weld pin Y 2

13 29270006751 调整垫片 Shim Y 2

14 29270006761 调整垫片 Shim Y 2

15 29270006771 调整垫片 Shim Y 2

16 29270009281 调整垫片 Shim Y 2

17 29270009291 调整垫片 Shim Y 2

18 29270010641 副车架 Rear axle bridge Y 1

19 29270006741 套 Sleeve Y 2

20 29250000301 垫片 Shim Y 4

21 29250000291 通油螺栓 Bolt Y 2

22 29270006711 机油滤清器支架 Bracket Y 1

23 4011000447 螺栓GB16674-M10*20EpZn-8.8 Bolt Y 2

24 29270006701 盖板 Cover plate Y 2

25 4011000102 螺栓GB5783-M8*16EpZn-8.8 Bolt Y 8

26 4015000256 垫圈GB96.1-8EpZn-300HV Washer Y 8

27 4016000194 开口销GB91-8*50EpZn-Q235A Split pin Y 1

28 29270006681 锁定杆后销轴 Pin Y 1

29 29270006671 锁定杆 Transport lock Y 1

30 29270000081 卡环 Lock ring Y 1

31 29270006651 锁定杆前销轴 Pin Y 1
32 4011000087 螺栓GB5783-M12*20EpZn-8.8 Screw Y 2
33 4040000001 垫圈LGB001-12 Washer Y 2
