LG918 4120006960 转斗油缸(3713CH) Tilt cylinder

1 4120006960002 缸筒总成24A139400 Cylinder tube Y 1
2 4120006960003 活塞杆总成24A114350 Piston rod Y 1
3 4120006539003 缸盖24C105130 Cover Y 1
4 4120006442004 衬套24S255251 556025 Bushing Y 1
5 4120006539004 钢丝挡圈-孔用24C090120 Retaining ring Y 1
6 4120006960004 密封件-缓冲24H005504 Sealing N 1
7 4120006960001 密封件包24A103210S Sealing kit Y 1
8 4120006960005 挡圈-U型圈24E005515 Retaining ring Y 1
9 4120006960001 密封件包24A103210S Sealing kit Y 1
10 4120006539006 钢丝挡圈-孔用24C090160 Retaining ring Y 1
11 4120006960001 密封件包24A103210S Sealing kit Y 1
12 4120006960001 密封件包24A103210S Sealing kit Y 1
13 4120006960001 密封件包24A103210S Sealing kit Y 1
14 4120006539007 活塞24C106120 Piston Y 1
15 4120006960001 密封件包24A103210S Sealing kit Y 1
16 4120006960001 密封件包24A103210S Sealing kit Y 1
17 4120006960001 密封件包24A103210S Sealing kit Y 1
18 4120006960001 密封件包24A103210S Sealing kit Y 2
19 4090000168 钢球GB308-5-GCr6 Ball Y 1
20 4120005872008 螺钉-内六角凹端紧定24T908161 Screw Y 1
21 4120006960006 轴套24C116340 Bushing Y 2
22 4120006960007 固定座24A154270 Anchor plate Y 1
23 4120006442009 垫圈-标准型弹簧24T401001 10 Washer Y 2
24 4120006442010 螺栓-六角头全螺纹24TB10253 M10*25L Screw Y 2
