LG933L I1900-2919001482 转向泵总成 Steering pump

1 4120001058 双联泵CBGj3100/1010-XF Gear pump Y 1

2 29110000043 泵用密封垫 Gasket Y 1

3 29190016081 吸油胶管 Hose Y 1

4 4017000018 喉箍JB8870-d70 Clamp Y 4

5 4011000475 螺栓GB16674-M10*30EpZn-8.8 Bolt Y 8

6 4041000056 分体法兰LGB117-312550 Flange half Y 1

7 4030000029 O形圈GB3452.1-37.5*3.55G O-ring Y 1

8 4041001932 软管LGB165-005060 Hose assembly Y 1

9 29190007921 直通接头体 Nipple Y 1

10 29120014931 垫圈 Washer Y 2

11 29120007651 接头 Nipple Y 1

12 4041002142 软管LGB125-004053 Hose assembly Y 1

13 29190005021 泵出油管 Hose assembly Y 1

14 4041000043 分体法兰LGB117-310490 Flange half Y 1

15 4030000026 O形圈GB3452.1-32.5*3.55G O-ring Y 1

16 29190012451 吸油钢管 Pipe Y 1

17 4011000479 螺栓GB16674-M12*30EpZn-8.8 Bolt Y 4

18 4041000011 分体法兰LGB117-314650 Flange half Y 1

19 4030000235 O形圈GB3452.1-43.7*3.55G O-ring Y 1

20 4012000003 螺柱GB898-M12*35EpZn-8.8 Stud Y 4

21 4013000011 螺母GB6170-M12EpZn-8 Nut Y 4

22 4015000168 垫圈GB97.1-12EpZn-300HV Washer Y 4

23 4041001063 组合接头LGB143-01810 Nipple Y 1

24 4030000490 O形圈GB3452.1-10.0*1.80G O-ring Y 1

25 4041000150 直接头LGB120-01814 Nipple Y 1

26 4041000767 O形圈LGB168-11124 O-ring Y 1
