L956F I1901-4120005046 泵(370142) Pump

1 4120000171044 挡圈41060100200 Retaining ring Y 1
2 4120000171045 旋转轴唇形密封圈43020200100 Sealing ring Y 2
3 4120003067001 前盖HGP2/a2 B 21040200310 Cover N 1
4 4120000171046 挡圈41060100100 Retaining ring Y 1
5 4120000171048 环形密封圈 44020100300 Sealing ring Y 1
6 4120000171049 滚针轴承42010100100 Needle bearing Y 8
7 4120000171050 定位套21020900110 Spacer sleeve Y 8
8 4120000171051 耳形挡片21020800110 Retaining ring Y 4
9 4120000171052 耳形密封垫21020700110 Sealing washer Y 4
10 4120000171053 侧板21020600110 Side board Y 4
11 4120005047003 主动齿轮轴ⅠHGP2080/a2B矩 Drive shaft Y 1
12 4120000171055 从动齿轮轴21020411010 Shaft Y 1
13 4120005047002 泵体ⅠHGP2080A 21061711110 Pump body Y 1
14 4120000171057 环形密封圈 44020100600 Sealing ring Y 2
15 4120005048006 中间体21131200110 Centering block N 1
16 4120005048010 主动齿轮轴21111108010 Drive shaft Y 1
17 4120005048007 从动齿轮轴21020408010 Shaft Y 1
18 4120005048009 泵体21131808010 Pump body N 1
19 4120005048013 环形密封圈 44020100400 Sealing ring N 1
20 4120005048014 O型圈43010101500 O-ring N 1
21 4120005048008 后盖21030508110 Cover N 1
22 4120005047001 螺钉M16x281 01017-11681 Screw Y 4
23 4120000171043 弹簧垫圈41050200600 Spring washer Y 4
24 4120001715017 螺钉41010101780 Screw Y 3
25 4120001715018 弹簧垫圈41050200500 Spring washer Y 3
26 4120005048012 螺钉41010100980 Screw Y 2
27 4120002432105 弹垫8-G97.1 41050200300 Spring washer Y 2
28 4120003067003 密封件包 Sealing ring kit Y 1
