B876F J2200-2622000172 行车制动总成 Travel brake

1 4120008076 胶管JB8406-B10*87 Hose assembly Y 2

2 26220001411 气管三通 Nipple Y 1

3 4190000343 喉箍JB8870-d16 Clamp Y 12

4 4041003147 组合接头LGB143-414×16 Elbow nipple Y 2

5 26220001821 三通接头 Nipple Y 1

6 4120005581 真空助力器总成 Vacuum booster Y 1

7 4120000419 胶管JB8406-B10*650 Hose Y 1

8 4013000373 螺母GB6170-M8flZnyc-8-480 Nut Y 11

9 4015000430 垫圈GB97.1-8flZnyc-300HV-480 Washer Y 11

10 4120004986 驻车制动踏板 Brake pedal Y 1

11 26220001751 定位支架 Bracket Y 1

12 4011001295 螺栓GB16674.1-M8*25flZnyc-8.8-480 Screw Y 2

13 4011001296 螺栓GB16674.1-M8*20flZnyc-8.8-480 Screw Y 4

14 4041002377 管夹LGB169-A20*12.5 Clamp Y 3

15 4011001302 螺栓GB16674.1-M10*16flZnyc-8.8-480 Screw Y 3

16 4041002904 软管LGB125-004191 Hose assembly Y 1

17 26220001771 桥油管 Pipe Y 2

18 4041001023 组合接头LGB143-01608 Nipple Y 2

19 4120004696 直通接头1CO-16-06 Nipple Y 2

20 29180012401 隔板接头 Nipple Y 2

21 4013000378 螺母GB6173-M16*1.5flZnyc-05-480 Nut Y 2

22 4011001305 螺栓GB16674.1-M8*45flZnyc-8.8-480 Screw Y 1

23 4015000434 垫圈GB97.1-20flZnyc-300HV-480 Washer Y 3

24 26220001161 拉伸弹簧 Spring Y 2

25 4120008914 胶管F481CACF080804-210 Hose assembly Y 1

26 26220001811 负压气管 Hose assembly Y 1

27 4090000257 胶管HG2491-10*300 Hose Y 2

28 26220000841 连杆 Connecting rod Y 2

29 4013000442 螺母GB6171-M10*1.25flZnyc-10-480 Nut Y 2

30 4016000131 销轴GB882-B10*32EpZn-35 Clevis pin Y 2

31 4016000183 开口销GB91-3.2*22EpZn-Q235A Split pin Y 2
32 4041002905 软管LGB125-004154 Hose assembly Y 1
33 26220000881 气管三通 Nipple Y 1
