B876F C0548-4110003513 离合器4661.172.023 Clutch assembly

1 4110003513115 离合器4661.272.034 Clutch N 1
2 4110003513116 活塞4661.372.024 Piston N 1
3 4110003513015 O型圈0634.313.395 O-ring Y 1
4 4110003513108 O型圈115X3 0634.313.219 O-ring Y 1
5 4110003513117 弹簧垫圈0732.043.001 Spring washer N 7
6 4110003513033 止推垫片0635.290.035 Thrust washer N 3
7 7200001475 卡环0630501031 Lock ring Y 2
8 4110003513010 滚轴轴承4661.201.005 Roller bearing Y 1
9 4110003513089 内摩擦片0501.232.653 Friction disc Y 13
10 4110003513090 外摩擦片0501.319.274 Friction disc Y 13
11 4110003513118 垫板0501.323.335 Gasket N 1
12 4110003513091 受压盘0501.326.779 Pressure plate N 1
13 4110003513092 固位环h=2,50 0730.301.866 Snap ring Y 1
14 4110003513093 固位环h=2,75 0730.301.867 Snap ring Y 1
15 4110003513094 固位环h=3,00 0730.301.868 Snap ring Y 1
16 4110003513095 固位环h=3,25 0730.301.869 Snap ring Y 1
17 4110003513096 固位环h=3,50 0730.301.870 Snap ring Y 1
18 4110003513097 固位环h=3,75 0730.301.871 Snap ring Y 1
19 4110003513098 固位环h=4,00 0730.301.872 Snap ring Y 1
20 4110003513119 齿轮总成4661.372.044 Gear N 1
21 4110003513011 密封圈0734.401.309 Sealing ring N 2
22 4110003513034 滚针轴承0635.302.034 Needle bearing N 2
23 4110003513035 定位环0635.290.063 Locating ring N 2
24 4110003513036 滚针轴承0735.321.579 Needle bearing N 2
25 4110003513120 轴衬0730.260.792 Bushing N 1
26 4110003513084 滚轴轴承4661.201.002 Roller bearing Y 1
27 4110003513085 密封环0734.401.296 Sealing ring Y 1
