B876F C0545-4110003513 离合器4661.175.008 Clutch assembly

1 4110003513082 离合器4661.275.006 Clutch N 1

2 4110003513013 活塞4661.375.019 Piston N 1

3 4110003513014 O型圈0634.313.005 O-ring Y 1

4 4110003513015 O型圈0634.313.395 O-ring Y 1

5 4110003513017 压缩弹簧0732.042.926 Compression spring N 1

6 4110003513018 弹簧座4661.302.005 Spring brace N 1

7 4110000367065 弹性挡圈40*1.75 0630 501 031 Retaining ring Y 2

8 4110003513083 滚轴轴承4661.201.004 Roller bearing Y 1

9 4110003513084 滚轴轴承4661.201.002 Roller bearing Y 1

10 4110003513016 垫板4661.202.026 Gasket N 1

11 4110003513021 内摩擦片0501.232.652 Friction disc Y 10

12 4110003513022 外摩擦片0501.321.410 Friction disc Y 10

13 4110003513023 受压盘0501.321.411 Pressure plate N 1

14 4110003513024 固位环h=2,50 0730.514.792 Snap ring Y 1

15 4110003513025 固位环h=2,75 0730.514.793 Snap ring Y 1

16 4110003513026 固位环D-TEIL*h=3,00 0730.514.794 Snap ring Y 1

17 4110003513027 固位环h=3,25 0730.514.795 Snap ring Y 1

18 4110003513028 固位环h=3,50 0730.514.796 Snap ring Y 1

19 4110003513029 固位环h=3,75 0730.514.797 Snap ring Y 1

20 4110003513030 固位环h=4,00 0730.514.798 Snap ring Y 1

21 4110003513032 齿轮总成4661.376.001 Gear N 1

22 4110003513033 止推垫片0635.290.035 Thrust washer N 2

23 4110003513034 滚针轴承0635.302.034 Needle bearing N 2

24 4110003513035 定位环0635.290.063 Locating ring N 2

25 4110003513036 滚针轴承0735.321.579 Needle bearing N 2

26 4110003513085 密封环0734.401.296 Sealing ring Y 2
