WD10G220E23（DHD10G0618） A01159-4110003316 Tensioner and belt group
WD10G220E23（DHD10G0618） A01159-4110003316 Tensioner and belt group
1 4110001015025 多楔带612600090682 Belt Y 1
2 4110001015026 多楔带612600061349 Belt Y 1
3 4110000924112 六角法兰面螺栓90011400001 Screw Y 1
4 4110001015023 张紧轮总成612600061510 Tension pulley Y 1
5 4110000924170 1型六角螺母90003871252 Nut Y 4
6 4110000924169 弹簧垫圈 90003931102 Spring washer Y 4
7 4110001015024 张紧轮座612600012921 Seat Y 1
8 4110000924113 双头螺柱M8*22 90003813429S Stud Y 4
