WD10G220E23（DHD10G0618） A01150-4110003316 Turbocharger oil pipe group

1 4110000924079 内六角圆柱头螺钉90003862427 Screw Y 2
2 4110000556253 自锁垫圈188250083 Washer Y 4
3 4110003450019 增压器油管总成612600117233 Pipe Y 1
4 4110001985016 进油管垫片612600114275 Gasket Y 1
5 4110001592025 六角头螺栓 90003802411 Screw Y 2
6 4110001592166 单管夹子612600110404 Clamp Y 2
7 4110001554016 管接头螺母90003559513 Nut Y 1
8 4110001554017 卡套90003559563 Sleeve Y 1
9 4110000556062 回油管法兰垫片61260110048 Gasket Y 1
10 4110003450008 增压器润滑油管612600110659 Pipe Y 1
11 4110000556063 回油管螺栓61460070014 Screw Y 2
12 4110001592030 软管卡箍 90003989301 Clamp Y 2
13 4110000556229 油路连接胶管612600112716 Hose Y 1
14 4110000556064 回油弯管612600070097 Pipe Y 1
