WD10G220E23（DHD10G0618） A01141-4110003316 Fuel injection pump group

1 4110000924148 内六角圆柱头螺钉612600082135 Screw Y 2
2 4110000556253 自锁垫圈188250083 Washer Y 2
3 4110002872005 平垫圈90014040007 Plain washer Y 2
4 4110001016014 喷油泵612601080878 Injection pump Y 1
5 4110000924141 双头螺柱90003813532S Stud Y 7
6 4110000591035 2型全金属六角锁紧螺母90003888452 Nut Y 7
7 4110001015042 喷油泵法兰612600082057 Flange Y 1
8 4110000924023 密封圈612600080400 Gasket Y 1
9 4110001015046 喷油泵齿轮612600082058 Gear Y 1
10 4110001755049 六角法兰面承面带齿螺栓90011430034 Screw Y 2
11 4110000924061 六角法兰面承面带齿螺栓90011430008 Screw Y 2
12 4110001015044 喷油泵支架612600082142 Bracket Y 1
13 4110001015045 喷油泵托架612600082094 Bracket Y 1
14 4110001015043 喷油泵支架612600082141 Bracket Y 1
15 4110000924144 六角法兰面承面带齿螺栓90011430012 Screw Y 3
16 4110000924080 弹簧垫圈90003931122 Spring washer Y 2
17 4110000924145 1型六角螺母90003871305 Nut Y 2
18 4110000924150 空心螺栓612639000047 Eye bolt Y 1
19 4110000556132 密封垫圈612600080246 Sealing ring Y 2
20 4110001015126 润滑油进油管总成612600082966 Pipe Y 1
21 4110002872006 平垫圈90014040008 Plain washer Y 4
22 4110000924142 空心螺栓90003962612 Eye bolt Y 1
23 4110000846102 密封垫圈612600050042 Washer Y 2
24 4110000924038 冒烟限制器空气管总成61560080159 Tube Y 1
25 4110000924044 输油泵612600082504 Fuel pump Y 1
