LFT26 K2700-2927002241 后车架附件 Accessories

1 4030000065 油杯JB7940.1-M10*1 Lubricating nipple Y 6

2 29250014121 接头 Nipple Y 5

3 29270022421 润滑油管 Lubricating pipe Y 2

4 29270018741 支架 Bracket N 1

5 4011001241 螺栓GB5783-M12*25flZnyc-8.8-480 Screw Y 4

6 4015000428 垫圈GB97.1-12flZnyc-300HV-480 Washer Y 10

7 29270010761 板 Cover plate Y 1

8 29250000291 通油螺栓 Bolt Y 5

9 29250000301 垫片 Shim Y 17

10 29270012681 转向销轴 Pin Y 2

11 4043000032 垫片LGB303-50*90*1 Shim Y 2

12 29270009101 走线胶套 Rubber sleeve Y 2

13 4015000436 垫圈GB97.1-16flZnyc-300HV-480 Washer Y 10

14 4011001387 螺栓GB5783-M16*45flZnyc-10.9-480 Bolt Y 2

15 29270009381 销轴 Pin Y 1

16 29270009461 防尘圈 Sealing ring Y 2

17 4015000011 挡圈GB893.1-130-65Mn Retaining ring Y 2

18 4021000233 关节轴承GB9163-GE90ES-2RS Spherical plain bearing Y 1

19 29270017791 润滑油管 Pipe Y 1

20 29270009421 塑料塞 Plastic plug Y 2

21 29270009431 销 Pin Y 1

22 29270009441 隔套 Sleeve Y 1

23 29270009451 套 Sleeve Y 2

24 4011001329 螺栓GB5782-M12*150flZnyc-8.8-480 Screw Y 8

25 4015000026 垫圈GB93-12-65Mn Spring washer Y 8

26 29270009471 盘 Disc Y 1

27 29270009501 垫片 Shim Y 2

28 29270009491 垫片 Shim Y 2

29 29270009481 垫片 Shim Y 2

30 4021000231 滚动轴承GB297-32316 Roller bearing Y 2

31 29270009911 隔套 Sleeve Y 1

32 4030000260 旋转轴唇形密封圈GB9877.1-B100*125*12 Sealing ring Y 2

33 29270009521 套 Sleeve Y 1

34 29270009511 盘 Disc Y 1

35 4013000368 螺母GB6170-M12flZnyc-8-480 Nut Y 8

36 29270009571 盘 Disc Y 1

37 4011001267 螺栓GB5782-M16*90flZnyc-8.8-480 Screw Y 4

38 29270009541 垫片 Shim Y 2

39 29270009561 垫片 Shim Y 2

40 29270009551 垫片 Shim Y 2

41 29270009531 垫片 Shim Y 2

42 4011001328 螺栓GB5783-M16*50flZnyc-8.8-480 Screw Y 4

43 4040000001 垫圈LGB001-12 Washer Y 2

44 4011001248 螺栓GB5783-M10*25flZnyc-8.8-480 Screw Y 10

45 4015000426 垫圈GB96.1-10flZnyc-300HV-480 Washer Y 10

46 29270000081 卡环 Lock ring Y 2

47 29270012331 锁定杆 Rod Y 1

48 29250010121 锁定销轴 Pin Y 2

49 29270012871 右盖板 Plate Y 1

50 29270022441 润滑油管 Lubricating pipe Y 1

51 29270022461 润滑油管 Lubricating pipe Y 1

52 4015000035 垫圈GB93-6-65Mn Spring washer Y 4

53 4014000510 螺钉GB818-M6*10flZnyc-4.8-480 Screw Y 4

54 29250000311 管夹 Clamp Y 2
