L989F J2300-2923000886 Paring brake assembly

1 29230008871 固定板 Plate Y 1

2 4011001294 螺栓GB16674.1-M10*20flZnyc-8.8-480 Screw Y 4

3 29120017111 缓冲套 Rubber sleeve Y 1

4 4120002703 接头GE12LR3/4EDOMDA3C Nipple Y 1

5 29230008881 阀块 Valve block Y 1

6 4120002705 蓄能器PED1-1.0L-31.5 Accumulator Y 1

7 4190000141 接头EW12LOMDA3C Nipple Y 2

8 4190000150 接头GE12LMEDOMDA3C Nipple Y 1

9 4120006452 胶管F381CACE121206-3520 Hose assembly Y 1

10 4190000176 过渡接头EW10LOMDA3C Nipple Y 2

11 4120002330 接头GE10L7/16UNFOMDCF Nipple Y 1

12 4120005455 胶管F481CACF101006-455 Hose assembly Y 1

13 4120008121 行车制动低压报警开关PS61-FS105BARF Pressure switch Y 1

14 4120004312 停车制动低压报警开关 Pressure switch Y 1

15 4120008122 紧急制动开关PS61-FS70BARF Pressure switch Y 1

16 4041000709 直接头LGB120-01616 Nipple Y 2

17 4041000780 O形圈LGB168-11324 O-ring Y 2

18 4120005454 胶管F481CACF101006-3040 Hose assembly Y 1

19 29230009811 橡胶垫 Rubber mat Y 1

20 29120017101 U形螺栓 U-bolt Y 1

21 4015000430 垫圈GB97.1-8flZnyc-300HV-480 Washer Y 2

22 4013000384 螺母GB889.1-M8flZnyc-8-480 Nut Y 2
