L989F I2110-4120008888 左转向油缸HSGL-10060432-918(3713CH) Steering cylinder

1 4120008888001 缸筒总成-左24A143500 Cylinder tube Y 1
2 4120008889002 活塞杆总成24A116750 Piston rod Y 1
3 4120008573003 缸盖24C105330 Cover Y 1
4 4120005494005 衬套24S260301 Bushing Y 1
5 4120008718004 钢丝挡圈-孔用24C090140 Retaining ring Y 1
6 4120006672005 密封件-缓冲24H006004 Sealing ring N 1
7 4120006672006 密封件-活塞杆24F206003 Sealing ring N 1
8 4120008718005 挡圈-U形圈24E00602C Retaining ring N 1
9 4120006672008 密封件-防尘24D206002 Sealing ring N 1
10 4120007051004 钢丝挡圈-孔用24C090170 Retaining ring Y 1
11 4120006742006 O形圈24K10950A O-ring N 1
12 4120008468003 挡圈-O形圈24M11000C Retaining ring N 1
13 4120006603013 O形圈24K310001 O-ring N 1
14 4120008889003 活塞24C106280 Piston Y 1
15 4120006603016 密封件-活塞24P210002 Sealing ring kit N 1
16 4120006672013 O形圈24K10600A Sealing ring N 1
17 4120008573006 挡圈-O形圈24M10650C Retaining ring N 2
18 4120006742009 支承环24G210001 Support ring N 1
19 4120006603018 钢球24U004001 Ball Y 1
20 4120006316010 螺钉-内六角凹端紧定24T906121 M6*12L Screw Y 1
21 4120003878021 关节轴承24U105001 Spherical plain bearing N 1
22 4120006441005 弹性挡圈-孔用-A型24T007501 Retaining ring N 1
23 4120008889004 密封件包24A104970S Sealing ring kit Y 1
