L989F I2000-2920001298 Steering system

1 4041000131 直接头LGB120-01412 Nipple Y 1

2 4041000784 O形圈LGB168-10924 O-ring Y 1

3 4041001047 组合接头LGB143-01406 Nipple Y 3

4 4041002411 管夹LGB169-A15*10 Clamp Y 1

5 4011001297 螺栓GB16674.1-M8*16flZnyc-8.8-480 Screw Y 1

6 4041001296 软管LGB125-003125 Hose assembly Y 1

7 29200012991 优先阀VLH-240部装 Priority valve N 1

8 4041001611 软管LGB128-010190 Hose Y 1

9 4041001872 软管LGB128-003160 Hose Y 1

10 4011001562 螺栓GB16674.1-M10*70flZnyc-8.8-480 Screw Y 2

11 29200013261 板 Plate Y 1

12 29200013271 板 Plate Y 1

13 29200013281 橡胶管夹 Clamp Y 1

14 29200012161 转向柱部装总成 Steering column N 1

15 29200012941 转向器BZZ8-1182部装A Diverter valve N 1

16 29200012971 管夹 Clamp N 2

17 4041000876 缓冲套LGB123-0322 Rubber sleeve Y 4

18 4011001286 螺栓GB16674.1-M8*55flZnyc-8.8-480 Screw Y 3

19 4015000430 垫圈GB97.1-8flZnyc-300HV-480 Washer Y 4

20 4013000373 螺母GB6170-M8flZnyc-8-480 Nut Y 4

21 29200013561 转向器回油胶管 Hose assembly Y 1

22 4041001425 软管LGB128-003055 Hose assembly Y 1

23 29200013051 板 Plate Y 1

24 4011001296 螺栓GB16674.1-M8*20flZnyc-8.8-480 Screw Y 1

25 29200011411 橡胶管夹 Clamp Y 1

26 29200011421 U型固定板 Plate Y 1

27 4011001512 螺栓GB5782-M8*60flZnyc-8.8-480 Bolt Y 1

28 29200013591 直接头LGB120-03022A Nipple N 1

29 4041000771 O形圈LGB168-11924 O-ring Y 1

30 29200013601 节流堵 Plug Y 1

31 4120007252 三通接头ET22LOMDCF Three-way nipple Y 1

32 4041000133 直接头LGB120-01414 Nipple Y 2

33 4041000767 O形圈LGB168-11124 O-ring Y 2

34 29200013041 管夹 Clamp Y 4

35 4041001252 缓冲套LGB123-0116 Rubber sleeve Y 2

36 4015000433 垫圈GB97.1-10flZnyc-300HV-480 Washer Y 3

37 29200013021 板 Plate Y 1

38 4011001300 螺栓GB16674.1-M10*30flZnyc-8.8-480 Screw Y 2

39 4013000370 螺母GB6170-M10flZnyc-8-480 Nut Y 3

40 4011001354 螺栓GB5782-M10*90flZnyc-8.8-480 Screw Y 1

41 29200013571 板 Plate Y 1

42 29200013061 橡胶管夹 Clamp Y 1
