L989F I1900-2919001715 Steering pump assembly

1 4041000779 O形圈LGB168-12331 O-ring Y 2

2 4041000188 直接头LGB120-03028 Nipple Y 2

3 4041001650 组合接头LGB143-13019 Joint lgb143-13019 Y 1

4 4041001508 软管LGB125-012050 Hose lgb125-012050 Y 1

5 4041001641 软管LGB164-014071 Hose lgb164-014071 Y 1

6 4120003340 柱塞泵A10VO110+AZPF16 Piston pump Y 1

7 4015000181 垫圈GB97.1-16EpZn-300HV Washer Y 2

8 4013000016 螺母GB6170-M16EpZn-8 Nut Y 2

9 4012000058 螺柱GB898-M16*45-EpZn-8.8 Stud Y 2

10 4120002330 接头GE10L7/16UNFOMDCF Nipple Y 1

11 4041001906 软管LGB126-004053 Hose Y 1

12 29190017261 转向泵出油法兰 Flange Y 1

13 4011000814 螺栓GB5783-M14*40EpZn-8.8 Bolt Y 1

14 29190013161 平垫圈-14 Washer Y 4

15 4030000029 O形圈GB3452.1-37.5*3.55G O-ring Y 1

16 4014000304 螺钉GB70.1-M14*40EpZn-10.9 Screw Y 3

17 4190000176 过渡接头EW10LOMDA3C Nipple Y 1

18 4120003065 梭阀WV-10 Shuttle valve Y 1

19 4120005281 接头EGEO10LMCF Nipple Y 1

20 29190017161 油路块 Block Y 1

21 4011001425 螺栓GB16674.1-M8*40flZnyc-8.8-480 Bolt Y 2

22 4120002987 接头GE30S15/8UNOMDCF Nipple Y 1

23 4120002006 接头EW30SOMDCF Nipple Y 1

24 4120005341 胶管F781C91C303016-600 Hose assembly Y 1

25 29190011021 先导泵吸油钢管 Pipe Y 1

26 4030000229 O形圈GB3452.1-22.4*2.65G O-ring Y 1

27 4011001389 螺栓GB5783-M6*25flZnyc-8.8-480 Screw Y 4

28 4015000424 垫圈GB97.1-6flZnyc-300HV-480 Washer Y 4

29 4041000774 螺塞LGB135-01422 Plug Y 1

30 4041000767 O形圈LGB168-11124 O-ring Y 1

31 29190017181 转向泵吸油钢管 Pipe Y 1

32 4030000474 O形圈GB3452.1-69.0*3.55G O-ring Y 1

33 4011001508 螺栓GB5783-M12*40flZnyc-8.8-480 Bolt Y 4

34 29200010471 平垫圈-12 Washer Y 4

35 4120001246 丝堵VSTI14*1.5EDA3C Plug Y 1

36 29190017201 转向泵吸油胶管 Hose assembly Y 1

37 4110000906 T型抱箍φ105.6（+2.4-5.6mm） Clamp Y 4

38 29190011041 过渡法兰 Flange Y 1

39 4030000097 O形圈GB3452.1-23.6*2.65G O-ring Y 1

40 4030000828 O形圈GB3452.1-41.2*2.65G O-ring Y 1

41 4012000075 螺柱GB899-AM10*110EpZn-8.8 Stud Y 4

42 4015000162 垫圈GB97.1-10EpZn-300HV Washer Y 4

43 29190011061 法兰 Flange Y 1

44 4014000541 螺钉GB70.1-M16*35flZnyc-10.9-480 Screw Y 4

45 4030000633 O形圈GB3452.1-128*3.55G O-ring Y 2

46 4015000363 挡圈GB893.1-34-65Mn Retaining ring Y 1

47 29190011051 驱动轴 Drive shaft Y 1

48 4041001817 软管LGB106-010062 Hose Y 1
