L989F F1310-4120009206 动臂油缸HSGF-170110861-1460B(3713CH ) Lifting cylinder

1 4120009206001 缸筒总成-左24A143880 Cylinder tube N 1
2 4120008911002 活塞杆总成24A116690 Piston rod Y 1
3 4120008911003 缸盖24A171930 Cover Y 1
4 4120005997003 衬套 24S2B0601 Bushing Y 1
5 4120006560008 钢丝挡圈-孔用24C090260 Retaining ring Y 1
6 4120005997004 密封件-缓冲 24H011004 Sealing ring N 1
7 4120008912004 密封件-活塞杆24F111002 Sealing ring N 1
8 4120006969003 挡圈-U形圈24E01101C Retaining ring Y 1
9 4120005997007 密封件-防尘 24D211002 Sealing ring N 1
10 4120006560009 钢丝挡圈-孔用24C090280 Retaining ring Y 1
11 4120005999008 O形圈24K11600A O-ring N 1
12 4120009098002 挡圈-O形圈24M11700C O-ring N 1
13 4120005999010 O形圈24K316701 O-ring N 1
14 4120008911004 活塞24A181120 Piston Y 1
15 4120008911005 密封件-活塞24P317003 Sealing ring N 1
16 4120005997012 O形圈 24K11100A O-ring Y 1
17 4120008911006 挡圈-O形圈24M11150C O-ring N 1
18 4120005999015 支承环24G217021 Sealing ring N 2
19 4120006560011 活塞背母24C103090 Nut Y 1
20 4120006560006 钢球24U006501 Ball N 1
21 4120006560007 螺钉-内六角凹端紧定24T910161 Screw Y 1
22 4120004488016 轴套24C051030 Bushing Y 1
23 4120006998003 销边防尘24R309520 Sealing ring N 2
24 4120004489011 内六角圆柱头螺钉24T520705 M20x70L Hex. socket screw Y 12
25 4120004488009 固定座24A151030 M16 Seat Y 1
26 4120009205002 密封件包24A105160S Sealing kit Y 1
