L989F F1300-2913002734 Lift cylinder

1 4120009205 动臂油缸HSGF-170*110*861-1460A Lifting cylinder Y 1

2 29130028251 右动臂缸小腔钢管 Pipe Y 1

3 4120002056 O形圈32.92*3.532-219N552-90 O-ring Y 12

4 4011001327 螺栓GB5782-M12*60flZnyc-10.9-480 Screw Y 8

5 4011001682 螺栓GB5782-M12*55flZnyc-10.9-480 Screw Y 8

6 4015000428 垫圈GB97.1-12flZnyc-300HV-480 Washer Y 24

7 4011001280 螺栓GB5783-M10*40flZnyc-8.8-480 Screw Y 8

8 4015000433 垫圈GB97.1-10flZnyc-300HV-480 Washer Y 8

9 29130027371 管夹A Clip Y 2

10 29130027381 管夹B Clip Y 2

11 29130025161 U形螺栓 U-bolt Y 12

12 29130025171 底板 Plate Y 12

13 4013000370 螺母GB6170-M10flZnyc-8-480 Nut Y 24

14 4015000426 垫圈GB96.1-10flZnyc-300HV-480 Washer Y 28

15 29130015011 固定板 Anchor plate Y 2

16 4011001248 螺栓GB5783-M10*25flZnyc-8.8-480 Screw Y 4

17 29130027551 左动臂缸大腔钢管 Pipe Y 1

18 29130028411 胶管 Hose assembly Y 4

19 4041002907 分体法兰LGB117-310501 Flange half Y 8

20 4011001604 螺栓GB16674.1-M12*45flZnyc-12.9-480 Screw Y 32

21 29130010821 管夹 Clamp Y 4

22 4041000869 缓冲套LGB123-0740 Rubber sleeve Y 4

23 4011001296 螺栓GB16674.1-M8*20flZnyc-8.8-480 Screw Y 2

24 4013000373 螺母GB6170-M8flZnyc-8-480 Nut Y 2

25 4015000430 垫圈GB97.1-8flZnyc-300HV-480 Washer Y 2

26 29130027601 右动臂联小腔钢管 Pipe Y 1

27 4041002128 软管LGB127-005075 Hose assembly Y 2

28 29130013691 支架 Bracket Y 2

29 4011001250 螺栓GB5783-M12*30flZnyc-8.8-480 Screw Y 8

30 29130027621 右动臂联大腔钢管 Pipe Y 1

31 4190000041 法兰总成M2M2HK-12 Flange Y 4
32 29130015151 压盘 Plate Y 2
33 4120000300 O形圈24.993.532-214N552-90 O-ring Y 2

34 4011000474 螺栓GB16674-M1025EpZn-8.8 Bolt Y 8
35 29130027641 左动臂联大腔钢管 Pipe Y 1
36 29130027661 左动臂联小腔钢管 Pipe Y 1
37 29130027391 右动臂缸大腔钢管 Pipe Y 1
38 29130028271 左动臂缸小腔钢管 Pipe Y 1
39 4120009206 动臂油缸HSGF-170110861-1460B Lifting cylinder Y 1
