L989F F1200-2912004166 Hydraulic control

1 29120021321 多路阀支架 Plate Y 1

2 4011000747 螺栓GB5783-M12*30EpZn-10.9 Screw Y 3

3 4015000168 垫圈GB97.1-12EpZn-300HV Washer Y 3

4 4120005411 胶管F481CACF101005-3330 Hose assembly Y 1

5 4120001023 胶管F481CACF101005-640 Hose assembly Y 2

6 4120001100 三通接头EL10LOMDA3C Three-way nipple Y 2

7 4120005412 胶管F481CACF101005-3270 Hose assembly Y 1

8 4120003342 多路阀M6-1452-30/3M6-22H Control valve Y 1

9 29120021901 回油垫块 Block Y 1

10 4030000029 O形圈GB3452.1-37.5*3.55G O-ring Y 2

11 4120006096 胶管F8111519242024-1700 Hose assembly Y 1

12 4120005414 法兰FHS35/10CFX Flange half Y 2

13 4120002990 O形圈OR37.69X3.53X O-ring Y 5

14 4011000528 螺栓GB16674-M10*100EpZn-8.8 Bolt Y 4

15 29120025641 进油钢管 Pipe Y 1

16 4120002056 O形圈32.92*3.532-219N552-90 O-ring Y 1

17 4120005415 法兰FHS64CFX Flange half Y 2

18 4011000467 螺栓GB16674-M12*45EpZn-8.8 Screw Y 6

19 29120021911 单向阀壳体 Housing cap Y 1

20 4120003464 单向阀L22-2 Check valve Y 2

21 4011000479 螺栓GB16674-M12*30EpZn-8.8 Bolt Y 14

22 4120005416 胶管F7816A1C163016-1790 Hose assembly Y 1

23 4120001099 法兰总成M2M2HK-16 Flange half Y 2

24 4120005417 胶管F481CACA101005-2560 Hose assembly Y 1

25 4120005418 胶管F481CACA101005-2600 Hose assembly Y 1

26 29120022141 胶管支架 Bracket Y 1

27 29120022151 管夹 Clamp Y 1

28 29120022161 管夹 Clamp Y 1

29 29120022171 压板 Plate Y 1

30 4011000601 螺栓GB16674-M10*120EpZn-8.8 Bolt Y 2

31 4013000007 螺母GB6170-M10EpZn-8 Nut Y 18

32 4015000162 垫圈GB97.1-10EpZn-300HV Washer Y 14

33 29120022241 支架 Bracket Y 1

34 29120022251 管夹 Clamp Y 2

35 29120022261 压板 Plate Y 1

36 4011000144 螺栓GB16674-M12*80EpZn-8.8 Bolt Y 2

37 4013000011 螺母GB6170-M12EpZn-8 Nut Y 2

38 4120005419 法兰FHS36CFX Flange half Y 1

39 4011000477 螺栓GB16674-M12*35EpZn-8.8 Bolt Y 9

40 4120005420 平面法兰FHSF36CFX Flange half Y 1

41 4120000302 O形圈47.22*3.532-225N552-90 O-ring Y 1

42 26370001971 管夹 Clamp N 1

43 4011000080 螺栓GB5783-M10*16EpZn-8.8 Bolt Y 1

44 4015000197 垫圈GB96.1-10EpZn-300HV Washer Y 1

45 4120002987 接头GE30S15/8UNOMDCF Nipple Y 1

46 4120006097 胶管F8111517242424-1390 Hose assembly Y 1

47 4190000355 法兰总成M1M1HK-24 Flange half Y 3

48 29120018191 回油块 Block Y 1

49 4011000447 螺栓GB16674-M10*20EpZn-8.8 Bolt Y 11

50 29120024311 回油块 Block Y 1

51 4120005422 胶管F481CACF181810-750-PG750 Hose assembly Y 1

52 4041003345 软管LGB166-014075 Hose assembly Y 1

53 4041001272 直接头LGB120-03628 Nipple Y 1

54 4041000779 O形圈LGB168-12331 O-ring Y 1

55 29120022181 单向阀壳体 Housing cap Y 1

56 29120022191 压盘 Plate Y 1

57 4120002000 法兰式直角接头WFS65/30SCFX Nipple Y 1

58 4120002765 法兰FHS65CFX Flange Y 2

59 4011000358 P-螺栓GB16674-M14*110EpZn-8.8 Screw Y 4

60 4011000493 螺栓GB16674-M8*90EpZn-8.8 Bolt Y 2

61 4013000033 螺母GB6170-M8EpZn-8 Nut Y 2

62 29120016351 固定板 Anchor plate Y 1

63 29120016741 管夹 Clamp Y 2

64 29120018121 压板 Plate Y 1

65 29120018131 管夹 Clamp Y 2

66 29120022201 回油支架 Bracket Y 1

67 29120038811 支架 Bracket Y 1

68 4011000081 螺栓GB5783-M10*20EpZn-8.8 Bolt Y 2

69 26370002901 自扎帆布套 Tarpaulin cover Y 4

70 4120005424 胶管F8111519243232-2980 Hose assembly Y 1

71 4190000354 法兰总成M1M1HK-32 Flange half Y 1

72 4120006098 胶管F781C96N301616-1850 Hose assembly Y 1

73 29120021481 回油钢管 Pipe Y 1

74 4011000230 螺栓GB16674-M10*65EpZn-8.8 Bolt Y 4

75 4041001057 螺塞LGB135-02732 Plug Y 2

76 4041000779 O形圈LGB168-12331 O-ring Y 3

77 4120003344 先导阀总成4THF6E Control lever Y 1

78 29430005541 先导阀过渡线束 Wiring harness Y 1

79 4190000180 接头GE10LREDOMDA3C Nipple Y 6

80 4120005426 胶管F481CACF101006-1480 Hose assembly Y 1

81 4120005427 胶管F481CACA101006-3220 Hose assembly Y 1

82 29120016021 固定板 Anchor plate Y 1

83 4120001954 滤油器PLF-C30*10 Hydraulic fluid filter Y 1

84 4030000276 O形圈GB3452.1-32.5*2.65G O-ring Y 2

85 29120015081 接头 Nipple Y 2

86 4120006448 胶管20411Y-16-06WZ/20491Y-16- Hose assembly Y 1

87 4120002830 蓄能器ELM0.75 Accumulator Y 1

88 29120020951 直接头 Nipple Y 1

89 4030000097 O形圈GB3452.1-23.6*2.65G O-ring Y 1

90 4041000771 O形圈LGB168-11924 O-ring Y 3

91 4120004439 先导油源块HF78539-12 Block Y 1

92 4041000604 直接头LGB120-01614 Nipple Y 1

93 4041000767 O形圈LGB168-11124 O-ring Y 3

94 29120021371 先导油源支架 Bracket Y 1

95 4041000143 直接头LGB120-02222 Nipple Y 2

96 4120005428 胶管F481CACF151508-1460 Hose assembly Y 1

97 4041000774 螺塞LGB135-01422 Plug Y 2

98 4011000303 螺栓GB5782-M8*85EpZn-8.8 Bolt Y 2

99 4015000072 垫圈GB97.1-8EpZn-300HV Washer Y 2

100 4041000577 直接头LGB120-03633 Nipple Y 1

101 4041000765 O形圈LGB168-12931 O-ring Y 1

102 4040000020 螺塞LGB135-01622 Plug Y 1

103 4041000780 O形圈LGB168-11324 O-ring Y 2

104 4041000709 直接头LGB120-01616 Nipple Y 1

105 4041000796 直接头LGB120-02628 Nipple Y 1

106 4041001006 组合接头LGB143-02616 Nipple Y 1

107 4030000501 O形圈GB3452.1-15.0*1.80G O-ring Y 1

108 4120002237 接头GEO10LMOMDCF Nipple Y 1

109 4120005431 胶管F381CACF101005-1830 Hose assembly Y 1

110 4120001246 丝堵VSTI14*1.5EDA3C Plug Y 2

111 4011000955 螺栓GB5783-M10*140EpZn-8.8 Screw Y 6

112 4041000508 螺塞LGB135-01824 Plug Y 1

113 4041000768 O形圈LGB168-11524 O-ring Y 1

114 26010000101 进气管支撑管夹 Clamp Y 1

115 4041001521 组合接头LGB143-11608 Nipple Y 1

116 4030000240 O形圈GB3452.1-8.00*1.80G O-ring Y 1

117 4120001954001 滤芯（先导滤清器滤芯)PLFX-30X10 Filter insert Y 1
