L989F F1000-2910003419 Hydraulic fluid tank assembly

1 29100034201 液压油箱 Hydraulic fluid tank N 1

2 29100035181 呼吸器胶管 Hose assembly Y 1

3 4017000008 喉箍JB8870-d40 Clamp Y 1

4 29100033751 液压油箱支架 Bracket Y 1

5 4011001562 螺栓GB16674.1-M10*70flZnyc-8.8-480 Screw Y 4

6 4043002980 孔板LGB343-100*40*5-2*12*70R5G Plate Y 2

7 4041003127 管夹LGB172-A20*28 Hose clamp Y 4

8 4011001530 螺栓GB16674.1-M12*60flZnyc-8.8-480 Screw Y 16

9 29100100531 大垫圈 Washer Y 8

10 29100100521 橡胶垫 Rubber washer Y 8

11 4043004609 防松套LGB331-12*22*28flZnyc-45 Attaching sleeve Y 4

12 4120000099 球阀MBS216-1/2″ Valve Y 1

13 29100009061 放油接头 Nipple Y 1

14 4041000508 螺塞LGB135-01824 Plug Y 1

15 4041000768 O形圈LGB168-11524 O-ring Y 1

16 4041001057 螺塞LGB135-02732 Plug Y 1

17 4041000779 O形圈LGB168-12331 O-ring Y 1

18 4043003375 防松套LGB331-12*30*30EpZn-45 Attaching sleeve Y 12
